Associated Numbers
18554 18554N 190-30146 246-30146 428000-1880 428000-1881 61231341 S-80237 UD02131SSpecifications
Kilowatt | 4 kW |
Length (L.1) | 317 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 48 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FREIGHTLINER | FL 50 | [MBE900] | 01.2000-12.2004 |
FREIGHTLINER | FL 60 | [MBE900] | 01.2000-12.2004 |
FREIGHTLINER | FL 70 | [MBE900] | 01.2000-12.2005 |
FREIGHTLINER | FL 80 | [MBE900] | 01.2000-12.2004 |
FREIGHTLINER | FS-65 | [MBE906] | |
FREIGHTLINER | M2 Business Class Mercedes | [MBE900] | 01.2003-12.2007 |
FREIGHTLINER | Saf-T-Liner-HDX |
Reference Information
18554 61231341 428000-1880 428000-1881 190-30146 246-30146 18554N UD02131S S-80237Video/Publications
18554 18554N 190-30146 246-30146 428000-1880 428000-1881 61231341 S-80237 UD02131SAdd Your Number
