Associated Numbers
190-20161 428000-0270 STN0270 UD02099SSpecifications
Kilowatt | 1.4 kW |
Length (L.1) | 193 mm |
Mount Hole Center - Center (O.1) | 82 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 25 mm |
Rotation | CW |
Spigot Diameter (A) | 39 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
GRUMMAN LLV | United States Postal Service 2.2 |
Reference Information
190-20161 428000-0270 STN0270 UD02099SVideo/Publications
190-20161 428000-0270 STN0270 UD02099SAdd Your Number
