Associated Numbers
190-30143 228000-9020 RE65817 S6134 UD02133S UNIT BOM 190-6362Specifications
Kilowatt | 4 kW |
Length (L.1) | 319 mm |
Mount Hole Center - Center (O.1) | 89 mm |
Mount Hole Center - Center (O.2) | 89 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 12.5 mm |
Mount Hole Diameter (C.2) | 12.5 mm |
Mount Hole Diameter (C.3) | 12.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 48 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JOHN DEERE | Natural Gas Bus 6068 | ||
JOHN DEERE | PowerTech Plus Engine 6.8 |
Reference Information
BOM RE65817 UNIT S6134 228000-9020 190-6362 190-30143 UD02133SVideo/Publications
190-30143 228000-9020 RE65817 S6134 UD02133S UNIT BOM 190-6362Add Your Number
