Associated Numbers
028000-7840 028000-7841 246-25140 28100-56110 28100-56111 91-29-5178 S-8113 UD11107SSpecifications
| Kilowatt | 2.5 kW |
| Length (L.1) | 298 mm |
| Mount Hole Center - Center (O.1) | 146 mm |
| Mount Hole Diameter (C.1) | M14x1.5 mm |
| Mount Hole Diameter (C.2) | M14x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 11 qty |
| No./Teeth (Replaces) | 11 qty |
| Pinion at Rest (B) | 14.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 105 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Land Cruiser 3.4 | [BJ60] | 01.1981-12.1984 |
Reference Information
028000-7840 028000-7841 S-8113 28100-56111 UD11107S 91-29-5178 28100-56110 246-25140Video/Publications
028000-7840 028000-7841 246-25140 28100-56110 28100-56111 91-29-5178 S-8113 UD11107SAdd Your Number
