Associated Numbers
02M911024H 02M911024HX 20432803OE 25-4298 254823D 300.913.132 3392 428000-7030 428000-7033 6040308 8080395 AEY2625 CST40308GS DENDSN962 DRS0796 DSN962 LRS02625 S6146 UD30033SSpecifications
Kilowatt | 2 kW |
Length (L.1) | 220 mm |
Mount Hole Center - Center (O.1) | 111 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 13 qty |
No./Teeth (Replaces) | 13 qty |
Pinion at Rest (B) | 61 mm |
Rotation | ACW |
Spigot Diameter (A) | 79 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
AUDI | A1 1.4 TFSi | [CPTA] | 01.2012- |
AUDI | Q3 2.0 TFSi Quattro | [CCZC] | 01.2011- |
AUDI | Q3 2.0 TFSi Quattro | [CPSA] | 01.2011- |
SEAT | Alhambra 1.4 TSi | [CAVA] | 01.2010- |
SEAT | Alhambra 1.4 TSi | [CNWB] | 01.2010- |
SEAT | Alhambra 1.4 TSi | [CTHA] | 01.2010- |
VW | Sharan 1.4 TSi | [CAVA] | 01.2010- |
VW | Sharan 1.4 TSi | [CTHA] | 01.2010- |
VW | Tiguan 1.4 TSi | [CAVA] | 01.2009- |
VW | Tiguan 1.4 TSi | [CAVD] | 01.2009- |
VW | Tiguan 1.4 TSi | [CAXA] | 01.2009- |
VW | Tiguan 1.4 TSi | [CTHA] | 01.2009- |
VW | Tiguan 1.4 TSi | [CTHD] | 01.2009- |
Reference Information
UD30033S 02M911024H 02M911024HX 428000-7030 DSN962 AEY2625 428000-7033 DRS0796 STR6441 20432803OE CST40308GS 25-4298 254823D LRS2625 300.913.132 DENDSN962 6040308 115964 3392 8080395 220864 336138 30199N S6146 LRS02625Video/Publications
02M911024H 02M911024HX 115964 20432803OE 25-4298 254823D 300.913.132 3392 428000-7030 428000-7033 6040308 8080395 AEY2625 CST40308GS DENDSN962 DRS0796 LRS02625 LRS2625 S6146 UD30033S 220864Add Your Number
