Specifications
Kilowatt | 4.5 kW |
Length (L.1) | 294 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
Mount Hole Diameter (C.3) | 11.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | DENSO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CUMMINS | Various Models | ||
PERKINS | Various Models | ||
SCANIA | K94 9.0 | [DSC9.15] | 01.1997-12.2000 |
SCANIA | T114 11.6 | [DC11.01] | 01.1996-12.2004 |
SCANIA | T114 11.6 | [DC11.02] | 01.1996-12.2004 |
SCANIA | T114 11.6 | [DC11.03] | 01.1996-12.2004 |
