Associated Numbers
17474 17956R 23300-AA48A 280-0365 428000-2300 91-29-5682 R-040960 S-80157 S6169 UD12046SSpecifications
Kilowatt | 1 kW |
Length (L.1) | 236 mm |
Mount Hole Center - Center (O.1) | 120 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 51 mm |
Rotation | ACW |
Spigot Diameter (A) | 65 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
SUBARU | Impreza 2.5 | 01.2005-12.2007 | |
SUBARU | Legacy 2.5 | 01.2005-12.2007 | |
SUBARU | Outback 2.5 | 01.2005-12.2007 |
Reference Information
17956R UD12046S 280-0365 R-040960 17474 428000-2300 91-29-5682 S6169 S-80157 23300-AA48AVideo/Publications
17474 17956R 23300-AA48A 280-0365 428000-2300 91-29-5682 R-040960 S-80157 S6169 UD12046SAdd Your Number
