Associated Numbers
113596 12498-63010 128000-4020 18009N 20432883BN 21163-2073 21163-2073A 246-06124 254510 6040388 630.526.092 71-29-18009 8845 91-29-5304 AM104559 AM108615 CST40388 CST40388AS CST40388ES CST40388GS CST40388OS CST40388RS DRS0793 EAA-111274 RS41285 S-8865 STR70198 UD12052SSpecifications
Kilowatt | 0.6 kW |
Length (L.1) | 180 mm |
Mount Hole Center - Center (O.1) | 99 mm |
Mount Hole Diameter (C.1) | M8x1.25 mm |
Mount Hole Diameter (C.2) | M8x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 20 mm |
Rotation | ACW |
Spigot Diameter (A) | 70 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JOHN DEERE | 170 | 01.1989-12.1990 | |
JOHN DEERE | 175 | 01.1987-12.1990 | |
JOHN DEERE | 245 | 01.1988-12.1994 | |
JOHN DEERE | F510 | 01.1990-12.2008 | |
JOHN DEERE | GS25 | 01.1997-12.2001 | |
JOHN DEERE | GS25 | ||
JOHN DEERE | GS30 | 01.1997-12.2003 | |
JOHN DEERE | GS45 | 01.1997-12.2003 | |
JOHN DEERE | GS45 | ||
JOHN DEERE | GT242 | 01.1993-12.1996 | |
JOHN DEERE | HD45 | 01.1997-12.2003 | |
JOHN DEERE | HD45 | ||
JOHN DEERE | LX172 | 01.1991-12.1996 | |
JOHN DEERE | LX176 | 01.1991-12.1996 | |
JOHN DEERE | LX176 | 01.1991-12.2008 | |
KAWASAKI | Engine | [FB460V] | |
KAWASAKI | Engine | [FC400V] | |
KAWASAKI | Engine | [FC401V] | |
KAWASAKI | Engine | [FC420V] | |
KUBOTA | T1460 | [GH410V] | 01.1995-12.2008 |
KUBOTA | T1460-40 | [GH410V] | 01.1995-12.2008 |
KUBOTA | T1460A-40 | [GH410V] | 01.1995-12.2008 |
KUBOTA | T1460B-40 | [GH410V] | 01.1995-12.2008 |
KUBOTA | T1560 | [GH420V] | 01.1995-12.2008 |
KUBOTA | T1560-40 | [GH420V] | 01.1995-12.2008 |
KUBOTA | T1560-44 | [GH420V] | 01.1995-12.2008 |
KUBOTA | T1560A-40 | [GH420V] | 01.1995-12.2008 |
KUBOTA | T1560A-44 | [GH420V] | 01.1995-12.2008 |
KUBOTA | T1560B-40 | [GH420V] | 01.1995-12.2008 |
KUBOTA | T1560B-44 | [GH420V] | 01.1995-12.2008 |
SCAG | 8W48 | [FC420V] | 01.1995-12.2008 |
Reference Information
20432883BN 630.526.092 CST40388 S-8865 6040388 18009N CST40388OS 8845 128000-4020 DRS0793 CST40388GS CST40388ES 91-29-5304 RS41285 AM108615 CST40388AS 246-06124 12498-63010 21163-2073 EAA-111274 STR70198 71-29-18009 211632093 CST40388RS 254510 AM104559 UD12052S STR6675 113596 21163-2073AVideo/Publications
113596 12498-63010 128000-4020 18009N 20432883BN 21163-2073 21163-2073A 246-06124 254510 6040388 630.526.092 71-29-18009 8845 91-29-5304 AM104559 AM108615 CST40388 CST40388AS CST40388ES CST40388GS CST40388OS CST40388RS DRS0793 EAA-111274 RS41285 S-8865 STR70198 UD12052SAdd Your Number
