Associated Numbers
115725 20432762OE 25-4439 255342 255342D 30243N 428000-4850 428000-4851 428000-6910 450.525.103 6040267 6G9N11000MA 6G9N11000MB AEX1087 AH5211001AC CS1579 CST40267 CST40267AS CST40267ES CST40267GS CST40267OS CST40267RS DRS0137 DSN1208 LR003468 LR007372 LR014060 LRS02766 SG1152 STN2849 STN2849XH STR70075 UD12387SSpecifications
Kilowatt | 2 kW |
Length (L.1) | 222 mm |
Mount Hole Center - Center (O.1) | 103 mm |
Mount Hole Center - Center (O.2) | 66 mm |
Mount Hole Center - Center (O.3) | 66 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | -5 mm |
Rotation | CW |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
LAND ROVER | Discovery Sport 2.2 SD4 | [224DT] | 01.2014-12.2015 |
LAND ROVER | Discovery Sport 2.2 TD4 | [224DT] | 01.2014-12.2015 |
LAND ROVER | Freelander 2.2 D | [224DT] | 02.2006- |
LAND ROVER | Freelander 2.2 D 4x4 | [224DT] | 06.2011- |
LAND ROVER | Freelander 2.2 D SD4 | [224DT] | 08.2010- |
LAND ROVER | Freelander 2.2 SD4 4x4 | [224DT] | 08.2010-10.2014 |
LAND ROVER | Freelander 2.2 TD4 | [224DT] | 01.2007- |
LAND ROVER | Freelander 2.2 TD4 4x4 | [224DT] | 10.2006-10.2014 |
LAND ROVER | Freelander 2.2 TD4 4x4 | [DW12BTED4] | 10.2006-10.2014 |
LAND ROVER | Range Rover Evoque 2.2 SD4 | [224DT] | 01.2011- |
LAND ROVER | Range Rover Evoque 2.2 TD4 | [224DT] | 01.2011- |
Reference Information
6G9N11000MA LR009432 6G9N11000MB LR007372 CST40267RS S6178 STN2849 255342 25-4439 CS1579 CST40267 CST40267ES 6040267 RNL428000-4850 336134 CST40267AS LR003468 STR6301 DRS0137 LR003469 30243N LRS2766 220706 DSN1208 CST40267OS AH521101AC AH5211001AC 115725 20432762OE 255342D CST40267GS 450.525.103 AEX1087 SG1152 STN2849XH UD12387S KTR901074204 STR70075 428000-4851 428000-4850 ANM12357X LR014060 S12DE0858A2 428000-6910 STRL614 LRS02766Video/Publications
115725 20432762OE 25-4439 255342 255342D 30243N 428000-4850 428000-4851 428000-6910 450.525.103 6040267 6G9N11000MA 6G9N11000MB AEX1087 AH5211001AC CS1579 CST40267 CST40267AS CST40267ES CST40267GS CST40267OS CST40267RS DRS0137 DSN1208 LR003468 LR007372 LR014060 LRS02766 LRS2766 RNL428000-4850 S6178 SG1152 STN2849 STN2849XH STR70075 STRL614 UD12387S 220706Add Your Number
