Associated Numbers
063280064010 17313 17714N 17714R 20432252OE 20432252RC 228000-5090 228000-5091 228000-5092 25-4041 254434 254434D 6040252 840.504.092 8EA012140-461 91-29-5504 96JV-11001-AB 96JV-11001-AC AEY2369 AJ83990 CST40252 CST40252AS CST40252ES CST40252GS CST40252OS CST40252RS DENDSN605 DRS0138 DSN605 LCA-1850AB LCA-1850CA LRS02369 S-8682 SS088 STR70095 UD12370SSpecifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 217 mm |
| Mount Hole Center - Center (O.1) | 110 mm |
| Mount Hole Diameter (C.1) | 11.5 mm |
| Mount Hole Diameter (C.2) | 11.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 37 mm |
| Rotation | CW |
| Spigot Diameter (A) | 62 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| JAGUAR | S-Type 4.0 V8 | [AJ-V8] | 01.1999-12.2002 |
| JAGUAR | S-Type 4.2 V8 | [AJ8FT] | 01.2003-12.2008 |
| JAGUAR | S-Type R 4.2 V8 | [AJ8FT] | 04.2002-10.2007 |
| JAGUAR | XF 4.2 | [SV82G] | 03.2008-04.2015 |
| JAGUAR | XJ 4.2 | [AJ8FT] | 05.2003-03.2009 |
| JAGUAR | XJ 8 3.2 | [AJ] | 01.1996-12.2002 |
| JAGUAR | XJ 8 4.0 | [BC] | 07.1979-05.2003 |
| JAGUAR | XJ 8 4.2 R-Type | [AJ8FT] | 01.2003-12.2009 |
| JAGUAR | XJ R 4.0 | [DC] | 07.1979-05.2003 |
| JAGUAR | XJ R 4.2 | [AJ8FT] | 05.2003-03.2009 |
| JAGUAR | XK 8 4.0 | [AJ26] | 03.1996-07.2005 |
| JAGUAR | XK 8 4.0 | [AJ27] | 03.1996-07.2005 |
| JAGUAR | XK 8 4.0 | [CC] | 01.1996-12.2002 |
| JAGUAR | XK 8 4.0 | [CE] | 01.1996-12.2002 |
| JAGUAR | XK 8 4.2 | [AJ8FT] | 08.2002-07.2005 |
| JAGUAR | XK 8 R 4.2 | [AJ8FT] | 08.2002-07.2005 |
| JAGUAR | XK R 4.0 V8 | [EC] | 01.1998-12.2005 |
| JAGUAR | XK R 4.2 V8 | [AJ-V8] | 01.2003- |
Reference Information
LCA-1850AB 96JV-11001-AC 96JV-11001-AB CST40252OS 20432252OE DSN605 AJ83990 S-8682 LCA-1850CA AEY2369 CST40252GS CST40252ES STR6428 63280064010 8EA012140-461 DRS0138 S12DE0756A2 UD12370S 840.504.092 5040653 17714R CST40252RS LRS2369 91-29-5504 17313 17714N SS088 DENDSN605 CST40252AS S12DE0756 254434 CST40252 LRS02369 228000-5091 228000-5092 6040252 STR70095 336261 20432252RC 25-4041 228000-5090 254434DVideo/Publications
063280064010 17313 17714N 17714R 20432252OE 20432252RC 228000-5090 228000-5091 228000-5092 25-4041 254434 254434D 6040252 840.504.092 8EA012140-461 91-29-5504 96JV-11001-AB 96JV-11001-AC AEY2369 AJ83990 CST40252 CST40252AS CST40252ES CST40252GS CST40252OS CST40252RS DENDSN605 DRS0138 LCA-1850AB LCA-1850CA LRS02369 LRS2369 S-8682 SS088 STR70095 UD12370SAdd Your Number
