Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 439.30 including GST
NZ$ 382.00 excluding GST
or four payments of $109.83
with
Learn More
each
S6190
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Associated Numbers
114282 18548N 190-25124 228000-0633 228000-7900 228000-7901 228000-7902 246-25249 254133 254133D 254133K 254133L 255016 255016L 3934119 3957593 45-5055 6040616 641.510.102 91-29-5694 91-29-5694N CST40616 CST40616AS CST40616ES CST40616GS CST40616OS CST40616RS DRS0357 EAA-161085 LRS03891 S-80179 STR70292Specifications
| Kilowatt | 4.50 kW |
| Length (L.1) | 298 mm |
| Mount Hole Center - Center (O.1) | 126 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Oil Sealed | Yes |
| Pinion at Rest (B) | 48 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 88 mm |
| Unit Type | DENSO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | CX130 | [4TA-390] | 01.2001-12.2007 |
| CASE | CX160 | [4TA-390] | 01.2002-12.2007 |
| CUMMINS | Engine 5.9 | [QSB] | 01.2004- |
| DRESSER | 510C 6B | 01.1990-12.2003 | |
| DRESSER | 515C 6B | 01.1990-12.2002 | |
| DRESSER | 520C 6B | 01.1990-12.2002 | |
| HITACHI | ZW140 4.5 | [QSB] | 01.2008- |
| HYUNDAI | HL 740-7 5.9 | [QSB] | 01.2004-12.2007 |
| HYUNDAI | HL740-7 5.9 | [QSB] | 01.2004-12.2007 |
| JCB | 414S 6.7 | [QSB] | 01.1995-12.2013 |
| JCB | 434S 6.7 | [QSB] | 01.2007-12.2013 |
| JCB | 436E 6.7 | [QSB] | 01.2007-12.2013 |
| KOMATSU | FD40ZT-7 | [6D102E] | 01.1998-12.2005 |
| KOMATSU | WA120 4B | 01.1997-12.2007 | |
| KOMATSU | WA120 6B | 01.1997-12.2007 | |
| KOMATSU | WA180-3 | [S6D102E-1] | 01.1997-12.2007 |
| KOMATSU | WA180-3PTC | [S6D102E-1] | 01.1997-12.2007 |
| KOMATSU | WA180 4B | 01.1997-12.2007 | |
| KOMATSU | WA180 6B | 01.1997-12.2007 | |
| KOMATSU | WA200-5 | [SAA6D102E-1] | 01.2006-12.2007 |
| KOMATSU | WA200PT-5 | [SAA6D102E-1] | 01.2006-12.2007 |
| KOMATSU | WA250 4B | 01.1997-12.2007 | |
| KOMATSU | WA250 6B | 01.1997-12.2007 | |
| KOMATSU | WA253 4B | 01.1997-12.2007 | |
| KOMATSU | WA253 6B | 01.1997-12.2007 |
Reference Information
| 18548N | WAI / TRANSPO |
| 190-25125 | ROBERT'S |
| 228000-0633 | DENSO |
| 228000-7900 | DENSO |
| 228000-7901 | DENSO |
| 228000-7902 | DENSO |
| 246-25249 | DIXIE |
| 255016 | KUHNER |
| 255016D | KUHNER |
| 255016L | KUHNER |
| 336443 | LOGISTIK |
| 3920644 | CUMMINS |
| 3922474 | CUMMINS |
| 3957592 | CUMMINS |
| 3957593 | CUMMINS |
| 395792 | CUMMINS |
| 3970101 | CUMMINS |
| 45-5055 | ELSTOCK |
| 5140096 | MEAT & DORIA |
| 641.510.102.050 | PSH |
| 641.510.102.260 | PSH |
| 641.510.102.440 | PSH |
| 641.510.102.510 | PSH |
| 91-29-5694 | WILSON |
| 91-29-5694N | WILSON |
| AI-80072 | AINDE |
| ANM12577X | ANDEL |
| DENDSN2041 | WOODAUTO |
| DSN2041 | DENSO |
| LRS03891 | LUCAS |
| LRS3891 | LUCAS |
| S134.637 | PSH |
| S144.142 | PSH |
| S24DE0096A2 | SIDAT |
| S6190 | AS-PL |
| S-80179 | DIXIE |
| STN7593 | KRAUF |
| STR6745 | ELECTROLOG |
| STR70292 | WOODAUTO |
Video/Publications
