Associated Numbers
113459 128000-8170 128000-8171 18988N 190-20138 20419631OE 228000-5790 228000-5791 246-20109 25-3023 254599 254960 428000-4020 6021136 680.501.112 860871 91-29-5370 91-29-5370N CST21136 CST21136AS CST21136ES CST21136GS CST21136OS CST21136RS DRS0361 LRS01539 S-8943 STR70329 UD12031SSpecifications
Kilowatt | 2 kW |
Length (L.1) | 222 mm |
Mount Hole Center - Center (O.1) | 126 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 27 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CATERPILLAR | Engine | [D17LIS] | 01.1996-12.2006 |
LISTER ENGINES | Engine | [LPA3] | 01.1985- |
LISTER ENGINES | Engine | [LPW3] | 01.1985- |
LISTER ENGINES | Engine | [LPW4] | 01.1985- |
LISTER ENGINES | Engine | [LPWS3] | 01.1985- |
LISTER ENGINES | Engine | [LPWS4] | 01.1985- |
LISTER PETTER | Engine | [LPA3] | 01.1985- |
LISTER PETTER | Engine | [LPW3] | 01.1985- |
LISTER PETTER | Engine | [LPW4] | 01.1985- |
LISTER PETTER | Engine | [LPWS3] | 01.1985- |
LISTER PETTER | Engine | [LPWS4] | 01.1985- |
LISTER PETTER | Engine | [LPWT4] | 01.1996-12.2006 |
Reference Information
113459 S12DE0718A2 75717970 STR70329 CGB-28170 91-29-5370N S-8943 18988N 25-3023 428000-4020 CST21136 CST21136ES UD12031S 254960 CST21136GS 190-20138 20419631OE 91-29-5370 CST21136OS 757-17970 CST21136AS STR6456 6021136 75726450 680.501.112 246-20109 128000-8171 254599 128000-8170 228000-5790 228000-5791 CST21136RS LRS1539 5040644 LRS01539 757-26450 DRS0361 860871Video/Publications
113459 128000-8170 128000-8171 18988N 190-20138 20419631OE 228000-5790 228000-5791 246-20109 25-3023 254599 254960 428000-4020 6021136 680.501.112 860871 91-29-5370 91-29-5370N CGB-28170 CST21136 CST21136AS CST21136ES CST21136GS CST21136OS CST21136RS DRS0361 LRS01539 LRS1539 S-8943 STR70329 UD12031SAdd Your Number
