Associated Numbers
116149 12499-63010 128000-7940 18048N 190-10277 21163-2093 246-06109 254540 71-29-18048 8845 91-29-5218 AM108615 RS41288 S-8498 SND0290 STN0051 UD12053SSpecifications
Kilowatt | 0.7 kW |
Length (L.1) | 181 mm |
Mount Hole Center - Center (O.1) | 101 mm |
Mount Hole Diameter (C.1) | M8x1.25 mm |
Mount Hole Diameter (C.2) | M8x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 19 mm |
Rotation | ACW |
Spigot Diameter (A) | 75 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JOHN DEERE | 180 | 01.1986-12.1990 | |
JOHN DEERE | 185 | 01.1986-12.1990 | |
JOHN DEERE | 260 | 01.1988-12.1991 | |
JOHN DEERE | 265 | 01.1988-12.1994 | |
JOHN DEERE | 325 | 01.1995-12.2005 | |
JOHN DEERE | F525 | 01.1990-12.2000 | |
JOHN DEERE | F710 | 01.1991-12.2001 | |
JOHN DEERE | GS75 | 01.1997-12.2003 | |
JOHN DEERE | GS75 | ||
JOHN DEERE | GT262 | 01.1992-12.1996 | |
JOHN DEERE | GT265 | 01.1995-12.2005 | |
JOHN DEERE | GT275 | 01.1995-12.1996 | |
JOHN DEERE | HD75 | 01.1997-12.2003 | |
JOHN DEERE | HD75 | ||
JOHN DEERE | LX186 | 01.1991-12.1991 | |
KAWASAKI | Engine | [FC540V] | |
KUBOTA | T1700H | [GH540V] | 01.1992-12.1995 |
KUBOTA | T1700HX | [GH540V] | 01.1992-12.1995 |
Reference Information
211632073A 91-29-5218 20432883BN 18048N 116149 2043200ABN 6040388 254540 UD12053S 8845 MAV423880A RS41288 21163-2093 S-8498 128000-7940 AM108615 CST40388AS 246-06109 STR6799 1249863010 CST40A00AS 6040A00.0 190-10277 SND0290 AM104559 71-29-18048 STN0051 12499-63010 211632073Video/Publications
116149 12499-63010 128000-7940 18048N 190-10277 21163-2093 246-06109 254540 71-29-18048 8845 91-29-5218 AM108615 RS41288 S-8498 SND0290 STN0051 UD12053SAdd Your Number
