Associated Numbers
16372 19175N 28100-0S031 428000-6511 428000-6513 91-29-5797 S-80526 UD12962SSpecifications
Kilowatt | 1.6 kW |
Length (L.1) | 203 mm |
Mount Hole Center - Center (O.1) | 91 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 26.5 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Sequoia 4.6 | 01.2010-12.2012 | |
TOYOTA | Tundra 4.6 | 01.2010-12.2016 |
Reference Information
19175N 16372 428000-6511 28100-0S031 91-29-5797 UD12962S 428000-6513 S-80526Video/Publications
16372 19175N 28100-0S031 428000-6511 428000-6513 91-29-5797 S-80526 UD12962SAdd Your Number
