Associated Numbers
12417566337 428000-5660 STN5660 UD13961SSpecifications
Kilowatt | 1.6 kW |
Length (L.1) | 197 mm |
Mount Hole Center - Center (O.1) | 92 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 20.5 mm |
Rotation | CW |
Spigot Diameter (A) | 76 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
BMW | 760 6.0 | (F01)[N57D30A] | 01.2010-12.2015 |
Reference Information
7566337 428000-5660 MAV424850 UD13961S CST40485GS 12417566337 6040485.1 12417579152 7579152 STN5660 20432584OEVideo/Publications
12417566337 428000-5660 STN5660 UD13961SAdd Your Number
