Information
428000-4620Associated Numbers
2810078150 428000-4620 428000-4622 STN4622 STN9622 UD02134SSpecifications
Kilowatt | 3 kW |
Length (L.1) | 279 mm |
Mount Hole Center - Center (O.1) | 141 mm |
Mount Hole Diameter (C.1) | 14.50 mm |
Mount Hole Diameter (C.2) | M14x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 11 qty |
OEM Product | No |
Pinion at Rest (B) | 31 mm |
Product Line | Standard Line |
Product Type | Brand new |
Rotation | CW |
Spigot Diameter (A) | 105 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Coaster | ||
TOYOTA | Engine | [N04C] |
Reference Information
20432000BN | REAL |
28100-78150 | TOYOTA |
428000-4620 | DENSO |
428000-4622 | DENSO |
6040000.0 | SANDO |
CST40000AS | CASCO |
MAV420000A | SIOM |
STN4622 | KRAUF |
STN9622 | KRAUF |
UD02134S | AS-PL |
