Associated Numbers
0001107088 0001107433 0001107434 0986018480 113271 12042 201230 201230D 201236 20513001 220675 228000-7590 228000-7591 228000-7593 28100-0D030 28100-0D130 28100-0d030 28100-0d050 28100-22040 28100-22041 6.0153.9 6010250 8EA012526-431 8EA738002-001 CST10250 CST10250AS CST10250ES CST10250GS CST10250OS CST10250RS EAA-121136 EAA-122871 JS1236 UD12379SSpecifications
Kilowatt | 1.1 kW |
Length (L.1) | 178 mm |
Mount Hole Center - Center (O.1) | 115 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 15 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Avensis 1.6 i 16V | [3ZZ-FE] | 10.2000-02.2003 |
TOYOTA | Avensis 1.8 i 16V | [1ZZ-FE] | 10.2000-02.2003 |
TOYOTA | Celica 1.8 16V TS | [2ZZ-GE] | 08.1999-09.2005 |
TOYOTA | Celica 1.8 VVTi 16V | [1ZZ-FE] | 08.1999-07.2005 |
TOYOTA | Corolla 1.4 | [4ZZ-FE] | 02.2000-01.2002 |
TOYOTA | Corolla 1.4 16V | [4ZZ-FE] | 02.2000-10.2001 |
TOYOTA | Corolla 1.4 16V | [4ZZ-FE] | 02.2000-11.2001 |
TOYOTA | Corolla 1.4 VVTi | [4ZZ-FE] | 01.2002- |
TOYOTA | Corolla 1.4 VVTi | [4ZZ-FE] | 01.2002-05.2004 |
TOYOTA | Corolla 1.4 VVTi | [4ZZ-FE] | 08.2002- |
TOYOTA | Corolla 1.6 | [3ZZ-FE] | 02.2000-01.2002 |
TOYOTA | Corolla 1.6 16V | [3ZZ-FE] | 02.2000-10.2001 |
TOYOTA | Corolla 1.6 16V | [3ZZ-FE] | 02.2000-11.2001 |
TOYOTA | Corolla 1.6 VVTi | [3ZZ-FE] | 01.2002- |
TOYOTA | Corolla 1.6 VVTi | [3ZZ-FE] | 08.2002- |
TOYOTA | Corolla 1.6 VVTi Verso | [3ZZ-FE] | 01.2002-05.2004 |
TOYOTA | Corolla 1.8 i 16V Verso | [1ZZ-FE] | 09.2001-05.2004 |
TOYOTA | Corolla 1.8 i WTL-i TS | [2ZZ-GE] | 01.2002- |
TOYOTA | Corolla 1.8 VVTL-i TS | [2ZZ-GE] | 10.2005- |
TOYOTA | RAV4 1.8 i 16V | [1ZZ-FE] | 08.2000-11.2005 |
Reference Information
003-T909 1107088 0001107088 000986018480 220675 LRT00244 201236 28100-76130 28100-0D030 S6234S 3T909 9518 28100-0D130 8EA012526-431 STM770 JS1236 12042 3T364 STR1188 986018480 25-2404 31244N 31244R MTT364 UD12379S S12BH0225A2 2810022040 2810022041 88212742 STR50185 SG0986 458485 MAV461160 003-T364 190.536.112 LRT244 MTT909Video/Publications
0001107088 003-T364 003-T909 0986018480 12042 190.536.112 201236 2280003282 25-2404 2810076130 31244N 31244R 3T364 3T909 458485 88212742 8EA012526-431 9518 JS1236 LRT00244 MAV461160 MTT364 MTT909 SG0986 STM770 STR50185 UD12379S 220675Add Your Number
