Associated Numbers
190.923.152 25-5102 255522D 28100-0Y110 28100-47190 428000-7700 428000-7701 428000-7702 428000-7703 428000-7704 428000-8380 428080-8381 6040399 9699 AEY3938 CST40399 CST40399AS CST40399ES CST40399GS CST40399OS CST40399RS DENDSN987 DSN987 J5212149 LRS03938 UD805289(DENSO)SSpecifications
Kilowatt | 1.6 kW |
Length (L.1) | 216 mm |
Mount Hole Center - Center (O.1) | 139 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 15 qty |
Pinion at Rest (B) | 27.5 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Verso S 1.3 | [1NR-FE] | 11.2010-10.2016 |
TOYOTA | Yaris 1.3 | [1NR-FE] | 09.2011- |
TOYOTA | Yaris 1.3 | [1NR-FKE] | 09.2011- |
Reference Information
CST40399ES UD805289(DENSO)S CST40399AS DSN987 428000-8380 190.923.152 25-5102 CST40399RS DENDSN987 428080-8381 9699 LRS3938 STR6755 255522D CST40399 6040399 AEY3938 428000-7700 J5212149 28100-0Y110 CST40399OS 336140 LRS03938 28100-47190 428000-7701 428000-7702 428000-7703 CST40399GS 428000-7704Video/Publications
190.923.152 25-5102 255522D 28100-0Y110 28100-47190 428000-7700 428000-7701 428000-7702 428000-7703 428000-7704 428000-8380 428080-8381 6040399 9699 AEY3938 CST40399 CST40399AS CST40399ES CST40399GS CST40399OS CST40399RS DENDSN987 J5212149 LRS03938 LRS3938 UD805289(DENSO)SAdd Your Number
