Associated Numbers
190.920.092 220940 25-5078 255439D 28100-26180 28100-26181 428000-9480 428000-9481 428000-9482 428080-9482 6040401 9638 AEX1244 CST40401 CST40401AS CST40401ES CST40401GS CST40401OS CST40401RS DENDSN1235 DSN1235 LRS03915 STN6180 UD805285(DENSO)SSpecifications
Kilowatt | 2 kW |
Length (L.1) | 202 mm |
Mount Hole Center - Center (O.1) | 122 mm |
Mount Hole Diameter (C.1) | M12x1.25 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 25 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | RAV4 2.0 D4-D | [1AD-FTV] | 01.2012- |
TOYOTA | RAV4 2.0 D4-D 4WD | [1AD-FTV] | 01.2012- |
TOYOTA | RAV4 2.2 D4-D 4WD | [2AD-FHV] | 01.2012- |
TOYOTA | RAV4 2.2 D4-D 4WD | [2AD-FTV] | 01.2012- |
Reference Information
428080-9482 6040401.1 CGB-55078 UD805285(DENSO)S DSN1235 DRS0953 6040401 255439D PRSE516 9638 190.920.092.260 28100-26181 STRE516 88215227 28100-26180 STN6180 LRS3915 428000-9482 STR70539 CST40401GS 220940 CST40401AS 428000-9481 DENDSN1235 20432104BN 428000-9480 STR6692 20432104OE 12409 AEX1244 190.920.092.050 LRS03915 25-5078Video/Publications
190.920.092 220940 25-5078 255439D 28100-26180 28100-26181 428000-9480 428000-9481 428000-9482 428080-9482 6040401 9638 AEX1244 CST40401 CST40401AS CST40401ES CST40401GS CST40401OS CST40401RS DENDSN1235 LRS03915 LRS3915 STN6180 UD805285(DENSO)SAdd Your Number
