Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 368.15 including GST
NZ$ 320.13 excluding GST
or four payments of $92.04
with
Learn More
each
S0451,S6041,S0451(SEG),S6246(DENSO),
S6246S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
428000-4051Associated Numbers
101450 101450D 114886 190.934.092 220708 25-5106 255231 255231D 28100-37020 28100-37021 28100-37030 28100-37031 28100-37032 33291N 3676 428000-4050 428000-4051 428000-4052 428000-4053 428000-4110 428000-4111 428000-4112 428000-4113 428000-4114 428080-4114 AEY2390 DENDSN1213 DRS0631 DS1741 DSN1213 LRS03945 S6246 STM1389 STN7680 UD20507SSpecifications
| Kilowatt | 1 kW |
| Length (L.1) | 201 mm |
| Mount Hole Center - Center (O.1) | 122 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 14.50 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Auris 1.6 | [1ZR-FAE] | 05.2009-09.2012 |
| TOYOTA | Auris 1.6 | [1ZR-FE] | 03.2007-09.2012 |
| TOYOTA | Auris 1.6 | [1ZR-FE] | 05.2009-09.2012 |
| TOYOTA | Auris 1.8 | [2ZR-FAE] | 02.2009-09.2012 |
| TOYOTA | Auris 1.8 4WD | [2ZR-FAE] | 02.2009-09.2012 |
| TOYOTA | Corolla Saloon 1.6 | [1ZR-FAE] | 01.2009- |
| TOYOTA | Corolla Saloon 1.6 | [1ZR-FE] | 01.2009- |
| TOYOTA | Corolla Saloon 1.6 Dual VVTi | [1ZR-FE] | 01.2007- |
| TOYOTA | RAV4 2.0 | [3ZR-FE] | 12.2012- |
| TOYOTA | RAV4 2.0 | [3ZR-FAE] | 03.2009- |
| TOYOTA | RAV4 2.0 | [3ZR-FAE] | 12.2008- |
| TOYOTA | RAV4 2.0 | [3ZR-FE] | 12.2012- |
| TOYOTA | RAV4 2.0 4WD | [3ZR-FAE] | 03.2009- |
| TOYOTA | RAV4 2.0 4WD | [3ZR-FAE] | 12.2008- |
| TOYOTA | RAV4 2.0 4WD | [3ZR-FAE] | 12.2012- |
| TOYOTA | Yaris 1.8 VVTi | [2ZR-FE] | 01.2007- |
Reference Information
| 101450 | KUHNER |
| 101450D | KUHNER |
| 114886 | CARGO |
| 190.934.092 | PSH |
| 20432344OE | REAL |
| 220708 | ERA |
| 25-5106 | ELSTOCK |
| 255231 | KUHNER |
| 255231D | KUHNER |
| 28100-0T030 | TOYOTA |
| 28100-0T030C | TOYOTA |
| 281000T050 | TOYOTA |
| 28100-0T060 | TOYOTA |
| 28100-37020 | TOYOTA |
| 28100-37021 | TOYOTA |
| 28100-37030 | TOYOTA |
| 28100-37031 | TOYOTA |
| 28100-37032 | TOYOTA |
| 33291N | WAI / TRANSPO |
| 3676 | CEVAM |
| 428000-4050 | DENSO |
| 428000-4051 | DENSO |
| 428000-4052 | DENSO |
| 428000-4053 | DENSO |
| 428000-4110 | DENSO |
| 428000-4111 | DENSO |
| 428000-4112 | DENSO |
| 428000-4113 | DENSO |
| 428000-4114 | DENSO |
| 428080-4114 | DENSO |
| 6040443.1 | SANDO |
| AEY2390 | AUTOELECTRO |
| CS1450 | HC PARTS |
| CST40443GS | CASCO |
| DENDSN1213 | WOODAUTO |
| DRS0631 | DELCO |
| DS1741 | DELCO |
| DSN1213 | DENSO |
| F032114886 | CARGO |
| LRS03945 | LUCAS |
| LRS3945 | LUCAS |
| MAV424430 | SIOM |
| S131.171 | PSH |
| S6246 | AS-PL |
| STM1323 | ROLLCO |
| STM1389 | ROLLCO |
| STN7680 | KRAUF |
| STR6156 | ELECTROLOG |
| STR6543 | ELECTROLOG |
| STX201059 | STARDAX |
| UD20507S | AS-PL |
Video/Publications
