Associated Numbers
16163 28100-0S050 428000-9090 428000-9091 91-29-5806 S-80401 STN0055 STN0055XH UD13966SSpecifications
Kilowatt | 2 kW |
Length (L.1) | 201 mm |
Mount Hole Center - Center (O.1) | 103 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 24 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
LEXUS | LX570 5.7 | 01.2013-12.2016 | |
TOYOTA | Land Cruiser 5.7 | 01.2013-12.2016 | |
TOYOTA | Sequoia 5.7 | 01.2011-12.2016 | |
TOYOTA | Tundra 5.7 | 01.2011-12.2016 |
Reference Information
428000-9090 16163 428000-9091 STN0055XH 19209N MAV420070A 28100-38080 28100-0S050 91-29-5806 6040007 STN0055 S-80401 UD13966S 20432700BN CST40007ASVideo/Publications
16163 28100-0S050 28100-38080 428000-9090 428000-9091 91-29-5806 S-80401 STN0055 STN0055XH UD13966SAdd Your Number
