Associated Numbers
150.579.132 25-4328 255280 36100-2A550 428000-7980 LRS02656 STN7980 STN7980YJ UD13964SSpecifications
| Kilowatt | 1.9 kW |
| Length (L.1) | 217 mm |
| Mount Hole Center - Center (O.1) | 102 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 17 mm |
| Rotation | CW |
| Spigot Diameter (A) | 77 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | i40 1.7 CRDi | [D4FD] | 01.2011- |
| HYUNDAI | ix35 1.7 CRDi | [D4FD-L] | 01.2010- |
| KIA | Carens 1.7 CRDi | [D4FD-L] | 01.2013- |
| KIA | Optima 1.7 CRDi | [D4FD-L] | 01.2012- |
| KIA | Sportage 1.7 CRDi | [D4FD-L] | 01.2010- |
Reference Information
CST40383AS LRS2656 MAV423830A STN7980 20432383BN 6040383.1 220760 STN7980YJ STR6732 361002A550SJ 20432383OE 255280 S6257S 36100-2A550 S12DE0559A2 150.579.132 6040383 116255 25-4328 428000-7980 5040610 CST40383GS LRS02656 UD13964SVideo/Publications
116255 150.579.132 25-4328 255280 36100-2A550 428000-7980 LRS02656 LRS2656 STN7980 STN7980YJ UD13964S S6257S 220760Add Your Number
