Associated Numbers
063280066010 12205 228000-7620 25-3351 254403 254403D 33177R 450.533.112 6040224 AEY2177 CST40224 CST40224AS CST40224ES CST40224GS CST40224OS CST40224RS DENDSN941 DRS0198 DS1308 DSN941 GNU4825 LRS02177 LRS2177 MSN8066 NAD101180 NAD101180E NAD180101 STN4620 UD805065(DENSO)SSpecifications
Kilowatt | 1.4 kW |
Length (L.1) | 217 mm |
Mount Hole Center - Center (O.1) | 110 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | 13 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 66 mm |
Rotation | ACW |
Spigot Diameter (A) | 55 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MG | ZT 160 2.5 | [25K4F] | 06.2001-07.2005 |
MG | ZT 180 2.5 | [25K4F] | 02.2004-10.2005 |
MG | ZT 190 2.5 | [25K4F] | 06.2001-07.2005 |
MG | ZT-T 160 2.5 | [25K4F] | 10.2001-07.2005 |
MG | ZT-T 180 2.5 | [25K4F] | 02.2004-10.2005 |
MG | ZT-T 190 2.5 | [25K4F] | 10.2001-07.2005 |
Reference Information
CST40224RS 63280066010 DSN941 228000-7620 NAD101180E CST40224 DS1308 CST40224GS 336532 6040224 CST40224ES STN4620 254403 450.533.112 LRS02177 CST40224AS DRS0198 LRS2177 DENDSN941 254403D AEY2177 MSN8066 CST40224OS UD805065(DENSO)S 33177R NAD180101 NAD101180 GNU4825 25-3351 12205 STR6292Video/Publications
063280066010 12205 228000-7620 25-3351 254403 254403D 33177R 450.533.112 6040224 AEY2177 CST40224 CST40224AS CST40224ES CST40224GS CST40224OS CST40224RS DENDSN941 DRS0198 DS1308 GNU4825 LRS02177 LRS2177 MSN8066 NAD101180 NAD101180E NAD180101 STN4620 UD805065(DENSO)SAdd Your Number
