Associated Numbers
246-31110 256001 428000-6030 428000-9910 560.501.103 6040334 87638510 87638510R 91-29-5823 CST40334 CST40334AS CST40334ES CST40334GS CST40334OS CST40334RS S-80445 STN6030 STN6030WD UD14901SSpecifications
Kilowatt | 3 kW |
Length (L.1) | 279 mm |
Mount Hole Center - Center (O.1) | 89 mm |
Mount Hole Center - Center (O.2) | 89 mm |
Mount Hole Center - Center (O.3) | 126 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 27 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CASE | 420 | [432T/M3] | 01.2008-12.2012 |
CASE | 420 CT | [432T/M3] | 01.2008-12.2012 |
CASE | 430 | [432T/M3] | 01.2008-12.2012 |
CASE | 435 | [334T/M2] | 01.2004-12.2008 |
CASE | 435 | [432T/M3] | 01.2008-12.2012 |
CASE | 440 | [445T/M3] | 01.2008-12.2012 |
CASE | 440 CT | [445T/M3] | 01.2008-12.2012 |
CASE | 445 CT | [432T/M3] | 01.2008-12.2012 |
CASE | 445 CT | [445/M2] | 01.2005-12.2007 |
CASE | 450 | [445T/M3] | 01.2008-12.2012 |
CASE | 450 CT | [445T/M2] | 01.2005-12.2007 |
CASE | 450 CT | [445T/M3] | 01.2008-12.2012 |
CASE | 465 | [445T/M3] | 01.2008-12.2012 |
NEW HOLLAND | C 185 | [334T/M2] | 01.2006-12.2011 |
NEW HOLLAND | C 190 | [445/M2] | 01.2006-12.2011 |
Reference Information
560.501.103 246-31110 91-29-5823 87638510R STN6030 CST40334OS 19856N 256001 428000-6030 CST40334 CST40334RS STN6030WD UD14901S 6040334 428000-9910 CST40334AS S-80445 CST40334ES CST40334GS 87638510Video/Publications
246-31110 256001 428000-6030 428000-9910 560.501.103 6040334 87638510 87638510R 91-29-5823 CST40334 CST40334AS CST40334ES CST40334GS CST40334OS CST40334RS S-80445 STN6030 STN6030WD UD14901SAdd Your Number
