Associated Numbers
112547 16235-63010 16235-63011 16235-63012 190-20275 20432581 20513076 228000-6320 228000-6321 246-15101 25-3480 6040185 690.520.132 8527 91-29-5813 CST40185AS CST40185GS DSN2087 LRS02308 S-80078 STN2547 STR30058 UD14892SSpecifications
Kilowatt | 1.4 kW |
Length (L.1) | 188 mm |
Mount Hole Center - Center (O.1) | 110 mm |
Mount Hole Diameter (C.1) | 9.5 mm |
Mount Hole Diameter (C.2) | 9.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 13 qty |
Pinion at Rest (B) | 18 mm |
Rotation | CW |
Spigot Diameter (A) | 66 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
AVANT | 640 1.5 | [V1505] | 01.2015- |
AVANT | R35 1.5 | [V1505] | 01.2015- |
BELOS | Trans Pro 3440 1.1 | [D1105-T] | 01.2008- |
MUSTANG | 2012 1.1 | [D1105] | 01.2007- |
RANSOMES | HR330T 1.1 | [D1105-T] | 01.2008- |
SCHAFFER | 2028 1.1 | [D1105] | 01.2010- |
SCHAFFER | 222S 1.1 | [D1105] | 01.2008- |
SCHAFFER | 2336 1.5 | [V1505] | 01.2008- |
SCHAFFER | 2345T 1.5 | [V1505-T] | 01.2016- |
SCHAFFER | 3033S 1.5 | [V1505-T] | 01.2004- |
SCHAFFER | 3046 1.5 | [V1505-T] | 01.2007- |
SCHAFFER | Comfort 45 1.5 | [V1505-T] | 01.2004- |
SCHAFFER | Nordic 50 HD 1.5 | [V1505-T] | 01.2016- |
SCHAFFER | Plus PRO 46 1.5 | [V1505-T] | 01.2006- |
Reference Information
PRSL252 690.520.132.051 CST40185AS S-80078 690.520.132.058 254151 K756161810 K756161811 20432581OE K757196810 17423-63012 6040185 UD14892S 7770002602 000F042000183 25-3480 6040185.1 20432581BN F042S00183 K7711968000 690.520.132.260 K771161800 F042000183 LRS2308 AET0908 228000-6320 228000-6321 K771196810 MAV421850 DSN2087 16235-63012 254151D STR6112 228080-6321 246-15101 16235-63010 S6277S 16235-63011 STRL252 LRS02308 STR30058 CST40185GS K757196800Video/Publications
STR30058 MAV421850 6040185.1 6040185.0 20432581OE 20432581BN 690.520.132.260 DSN2087 228080-6321 228000-6321 228000-6320 CST40185GS CST40185AS AET0908 UD14892S STRL252 PRSL252 690.520.132.051 LRS2308 LRS02308 254151D 17423-63012 16235-63012 16235-63011 16235-63010 25-3480 S-80078 246-15101 S6277SAdd Your Number
