Associated Numbers
10913N 190-30147 234-2637 246-30229 255603 2873K415 428000-2370 6040645 641.530.113 91-29-5829 CST40645 CST40645AS CST40645ES CST40645GS CST40645OS CST40645RS DENDSN2025 DSN2025 S-80442 STR70431 UD14814SSpecifications
Kilowatt | 7.8 kW |
Length (L.1) | 321 mm |
Mount Hole Center - Center (O.1) | 89 mm |
Mount Hole Center - Center (O.2) | 89 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
Mount Hole Diameter (C.3) | 11.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | DENSO |
Voltage | 24 V |
Wet Clutch | Yes |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
BARBER GREENE | BG600D | [C6.6] | |
BARBER GREENE | BG655D | [C6.6] | |
CATERPILLAR | 924H | [C6.6] | |
CATERPILLAR | 924HZ | [C6.6] | |
CATERPILLAR | 928H | [C6.6] | |
CATERPILLAR | 928HZ | [C6.6] | |
CATERPILLAR | 930H | [C6.6] | |
CATERPILLAR | AP500E | [C4.4] | |
CATERPILLAR | AP555E | [C4.4] | |
CATERPILLAR | AP600D | [C6.6] | |
CATERPILLAR | AP655C | [C6.6] | |
CATERPILLAR | AP655D | [C6.6] | |
CATERPILLAR | BG500E | [C4.4] | |
CATERPILLAR | BG555E | [C4.4] | |
CATERPILLAR | BG600D | [C6.6] | |
CATERPILLAR | BG655D | [C6.6] | |
CATERPILLAR | C6.6 | [C6.6] | |
CATERPILLAR | CP56 | [C6.6] | |
CATERPILLAR | CP563E | [3056E] | |
CATERPILLAR | CP56B | [C6.6] | |
CATERPILLAR | CP573E | [3056E] | |
CATERPILLAR | CP583E | [3056E] | |
CATERPILLAR | CP64 | [C6.6] | |
CATERPILLAR | CP64B | [C6.6] | |
CATERPILLAR | CP663E | [3056E] | |
CATERPILLAR | CP68B | [C6.6] | |
CATERPILLAR | CP74 | [C6.6] | |
CATERPILLAR | CP74B | [C6.6] | |
CATERPILLAR | CP76 | [C6.6] | |
CATERPILLAR | CS56 | [3116] | |
CATERPILLAR | CS56 | [C6.6] | |
CATERPILLAR | CS563E | [3056E] | |
CATERPILLAR | CS56B | [C6.6] | |
CATERPILLAR | CS573E | [3056E] | |
CATERPILLAR | CS583E | [3056E] | |
CATERPILLAR | CS64 | [C6.6] | |
CATERPILLAR | CS64B | [C6.6] | |
CATERPILLAR | CS663E | [3056E] | |
CATERPILLAR | CS683E | [3056E] | |
CATERPILLAR | CS68B | [C6.6] | |
CATERPILLAR | CS74 | [C6.6] | |
CATERPILLAR | CS74B | [C6.6] | |
CATERPILLAR | CS76 | [C6.6] | |
CATERPILLAR | CS78B | [C6.6] | |
CATERPILLAR | IT28G | [3056E] |
Reference Information
CST40645AS 234-2637 20432546OE CST40645 CST40645GS UD14814S CST40645ES DSN2025 MAV426450A 428080-2370 CST40645RS 641.530.113.262 20432546BN 641.530.113.261 336590 S24DE0148A2 S-80442 641.530.113 6040645.1 190-30147 190-30147NOE 2873K415 91-29-5829 6040645 10913N DENDSN2025 STR70431 428000-2371 255603 CST40645OS 428000-2370 641.530.113.050 S6285S 246-30229Video/Publications
10913N 190-30147 234-2637 246-30229 255603 2873K415 428000-2370 6040645 641.530.113 91-29-5829 CST40645 CST40645AS CST40645ES CST40645GS CST40645OS CST40645RS DENDSN2025 S-80442 STR70431 UD14814SAdd Your Number
