Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 487.19 including GST
NZ$ 423.64 excluding GST
or four payments of $121.80
with
Learn More
each
S6290S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
428000-2580Associated Numbers
191.519.102 246-25258 254444 428000-2580 428000-2581 45-4081 6040644 8605783 91-29-5819 CST40644 CST40644AS CST40644ES CST40644GS CST40644OS CST40644RS EAA-161295 LRS02409 S-80436 STR70484 UD14898SSpecifications
| Kilowatt | 4.50 kW |
| Length (L.1) | 298 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Diameter (C.1) | 10.50 mm |
| Mount Hole Diameter (C.2) | 10.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 27 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | DENSO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | 521D | 01.2003- | |
| CASE | 521E | [445TA/EGE] | 01.2008- |
| CASE | 621E | [668TA/M2] | 01.2003- |
| CASE | 721E | [668TA/E2] | 01.2003- |
| NEW HOLLAND | E175B | [F4GE9484D] | 01.2007- |
| NEW HOLLAND | E215B | [F4GE9684D] | 01.2007- |
| NEW HOLLAND | W110 | 01.2006- | |
| NEW HOLLAND | W110B | 01.2006- |
Reference Information
| 191.519.102 | PSH |
| 191.519.102.260 | PSH |
| 246-25258 | DIXIE |
| 254444 | KUHNER |
| 2810017050 | TOYOTA |
| 2810017051 | TOYOTA |
| 336480 | LOGISTIK |
| 428000-2580 | DENSO |
| 428000-2581 | DENSO |
| 45-4081 | ELSTOCK |
| 6040644 | SANDO |
| 8605783 | FORD |
| 91-29-5819 | WILSON |
| CST40644 | CASCO |
| CST40644AS | CASCO |
| CST40644ES | CASCO |
| CST40644GS | CASCO |
| CST40644OS | CASCO |
| CST40644RS | CASCO |
| LRS02409 | LUCAS |
| LRS2409 | LUCAS |
| S6290S | AS-PL |
| S-80436 | DIXIE |
| STR70484 | WOODAUTO |
| UD103006S | AS-PL |
| UD14898S | AS-PL |
Video/Publications
