Associated Numbers
438000-2660 89824822712 DRS1278 STN1541 UD15217SSpecifications
Kilowatt | 1.6 kW |
Length (L.1) | 195.5 mm |
Mount Hole Center - Center (O.1) | 123 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M12x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 8 mm |
Rotation | CW |
Spigot Diameter (A) | 75 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ISUZU | D-Max 1.9 Ddi | [RZ4E-TC] | 03.2017- |
ISUZU | D-Max 1.9 Ddi 4x4 | [RZ4E-TC] | 03.2017- |
Reference Information
STN1541 20432895BN 6040598 UD15217S 89824822712 8982482712 DRS1278 CST40598AS MAV425980A 438000-2660Video/Publications
438000-2660 8982482712 DRS1278 STN1541 UD15217SAdd Your Number
