Associated Numbers
120.562.092 25-4249 31200-RNA-A01 31200-RZP-E01 31200-RZP-G01 3360 428000-3420 428000-4521 428000-4540 428000-4541 8EA011611-891 AEX1086 DENDSN1390 DS4R7 DSKEG DSN1390 LRS02577 STR70419 UD15201SSpecifications
Kilowatt | 1.2 kW |
Length (L.1) | 224 mm |
Mount Hole Center - Center (O.1) | 126 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 33.5 mm |
Rotation | CW |
Spigot Diameter (A) | 75 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HONDA | Accord 2.0i | [F20A] | 01.2008- |
HONDA | Civic 1.6 | [R16A1] | 01.2005- |
HONDA | Civic 1.8 | [R18A1] | 01.2006- |
HONDA | Civic 1.8 | [R18A2] | 01.2006- |
HONDA | CR-V 2.0i | [R20A2] | 01.2007- |
HONDA | FR-V 1.8 | [R18A1] | 01.2007- |
Reference Information
LRS2577 17957R 17957N 114389 25-5509 CS1458 CGB-54249 DS4R5 3360 DS4R7 DS4RC DS4RD 31200RNA003 101458V 428000-4541 120.562.092.050 428000-4540 MAV423670A CST40367GS 31200RNAA11 AEY2577 DSKEQ 20432763OE S6300S 20432763BN 88212925 AEX1086 STR6233 25-4249 6040367.1 LRS4347 31200-RZP-E01 31200-RZP-G01 LRS02577 6040367 428000-4521 428000-4520 8EA011611-891 DSKEG STRL689 CST40367AS PRSL689 STR70419 DENDSN1390 LRS04347 428000-3420 DSN1390 120.562.092.260 31200-RNA-A01 UD15201S 101458D 101458Video/Publications
114389 120.562.092 25-4249 31200-RNA-A01 31200-RZP-E01 31200-RZP-G01 3360 428000-3420 428000-4521 428000-4540 428000-4541 8EA011611-891 AEX1086 CS1458 DENDSN1390 DS4R7 DSKEG LRS02577 LRS2577 STR70419 UD15201SAdd Your Number
