Associated Numbers
0986022611 115362 201364 31200-PWA-003 31200-PWA-G01 31200-PWA-G51 31200-PWC-901 31200-REJ-W01 33181N 428000-0360 428000-0950 428000-0960 428000-2060 8EA738-258-521 CST40256 CST40256AS CST40256ES CST40256GS CST40256OS CST40256RS DDVDS DDVDT DDVDU DRT2611 F032CS1364 JS1364 STN1364 UD20502SSpecifications
Kilowatt | 0.7 kW |
Length (L.1) | 213 mm |
Mount Hole Center - Center (O.1) | 91 mm |
Mount Hole Diameter (C.1) | M12x1.25 mm |
Mount Hole Diameter (C.2) | 11 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 33.5 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HONDA | Jazz 1.2 i | [L12A1] | 01.2002-12.2006 |
HONDA | Jazz 1.3i DSi | [L13A1] | 01.2002-12.2006 |
HONDA | Jazz 1.4 | 01.2002-12.2006 |
Reference Information
ANM24831X 31200-PWA-003 5040601 CST40256OS JS1364 428000-2060 LRS02181 CST40256GS 115362 986022611 201364 31200-REJ-W01 428000-0360 STM1170 J5214055 31200-PWA-G01 428000-0960 DDVTDHONDA F032CS1364 8EA738-258-521 CST40256RS DRT2611 33181N 000986022611 S12DE0516A2 CST40256 CST40256ES 31200-PWA-G51 31200-PWC-901 UD20502S 25-3354 STN1364 CST40256AS LRS2181 000F032CS1364 STR6234 DDVDT DDVDU STRL654 428000-0950 DDVDS DDVDUHONDAVideo/Publications
0986022611 115362 201364 31200-PWA-003 31200-PWA-G01 31200-PWA-G51 31200-PWC-901 31200-REJ-W01 33181N 428000-0360 428000-0950 428000-0960 428000-2060 8EA738-258-521 CST40256 CST40256AS CST40256ES CST40256GS CST40256OS CST40256RS DDVDS DDVDT DDVDU DRT2611 F032CS1364 J5214055 JS1364 STN1364 STRL654 UD20502SAdd Your Number
