Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 372.43 including GST
NZ$ 323.85 excluding GST
or four payments of $93.11
with
Learn More
each
S6316S
No stock in NZ currently
No stock in NZ currently
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
428000-6200Associated Numbers
063280073010 115644 12269 190.902.102 20432913 220928 25-4183 254608 254608D 28100-0N050 28100-33120 28100-33121 31239N 31239R 428000-6070 428000-6090 428000-6200 6040319 88214089 8EA012140-511 9744 CS1549 CST40319 DENDSN946 DRS0657 DS1767 DSN946 EAA-141329 J5212139 J5212148 LRS02511 MSN8073 SG1137 STM1320 STN4424 STR70459 UD16948SSpecifications
| Kilowatt | 2 kW |
| Length (L.1) | 230 mm |
| Mount Hole Center - Center (O.1) | 121 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 13 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Auris 1.4 D-4D | [1ND-TV] | 03.2007-09.2012 |
| TOYOTA | Corolla 1.4 D-4D | [1ND-TV] | 10.2006-07.2014 |
| TOYOTA | Urban Cruiser 1.4 D-4D | [1ND-TV] | 01.2009-04.2014 |
| TOYOTA | Urban Cruiser 1.4 D-4D 4WD | [1ND-TV] | 01.2009-04.2014 |
| TOYOTA | Verso S 1.4 D4-D | [1ND-TV] | 11.2010-10.2016 |
| TOYOTA | Yaris 1.4 D | [1ND-TV] | 09.2011- |
| TOYOTA | Yaris 1.4 D-4D | [1ND-TV] | 08.2005-12.2012 |
Reference Information
| 063280073010 | MAGNETI MARELLI |
| 115644 | CARGO |
| 12269 | EAI |
| 190.902.102.050 | PSH |
| 190.902.102.260 | PSH |
| 20432913OE | REAL |
| 220928 | ERA |
| 25-4183 | ELSTOCK |
| 254608 | KUHNER |
| 254608D | KUHNER |
| 28100-0N050 | TOYOTA |
| 28100-33100 | TOYOTA |
| 28100-33120 | TOYOTA |
| 28100-33121 | TOYOTA |
| 31239N | WAI / TRANSPO |
| 31239R | WAI / TRANSPO |
| 428000-6070 | DENSO |
| 428000-6071 | DENSO |
| 428000-6090 | DENSO |
| 428000-6200 | DENSO |
| 6040319.1 | SANDO |
| 88214089 | POWERMAX |
| 8EA012140-511 | HELLA |
| 9744 | CEVAM |
| AEX1109 | AUTOELECTRO |
| AEY2511 | AUTOELECTRO |
| ASM1197 | APEC |
| CGB-23252 | AINDE |
| CS1549 | HC PARTS |
| CST40319GS | CASCO |
| DENDSN946 | WOODAUTO |
| DRS0657 | DELCO |
| DRS0699 | DELCO |
| DS1767 | DELCO |
| DSN946 | DENSO |
| F032115644 | CARGO |
| J5212139 | HERTH+BUSS |
| J5212148 | HERTH+BUSS |
| LRS02511 | LUCAS |
| LRS2511 | LUCAS |
| MSN8073 | MAGNETI MARELLI |
| NPANSM1197 | NAPA |
| PRSF475 | 3EFFE |
| S12DE0590A2 | SIDAT |
| S131.239 | PSH |
| S6316S | AS-PL |
| SG1137 | GHIBAUDI |
| STM1320 | ROLLCO |
| STN4424 | KRAUF |
| STR6414 | ELECTROLOG |
| STR70459 | WOODAUTO |
| STRF475 | 3EFFE |
| STX210249 | STARDAX |
| STX210249R | STARDAX |
| UD16948S | AS-PL |
| UD20832S | AS-PL |
Video/Publications
