Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 365.04 including GST
NZ$ 317.43 excluding GST
or four payments of $91.26
with
Learn More
each
S6327S
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
428000-9061Associated Numbers
428000-9061 UD20557S CST40427GS 3350 DSN1234 25-5277 STN4690 LRS04114 190.926.092 20432724OE 6040427.1 DRS0924 DENDSN1234Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 203 mm |
| Mount Hole Center - Center (O.1) | 122 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.4) | 11 mm |
| Mount Hole Diameter (C.5) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 13 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Auris 1.4 D-4D | [1ND-TV] | 01.2012- |
| TOYOTA | Corolla 1.4 D-4D | [1ND-TV] | 01.2013- |
| TOYOTA | Yaris 1.4 D-4D | [1ND-TV] | 01.2014- |
Reference Information
190.926.092.050 88215038 428080-9061 DSN1234 6040427.1 116472 UD20557S LRS04114 STRJ087 28100-0N110 LRS4114 20432724OE 256329D CST40427GS AEY2511 STR6778 STX210259R 3350 428000-9061 DRS0924 428000-9060 S6327S STX210259 DENDSN1234 25-5277Video/Publications
