Information
428000-6800Associated Numbers
428000-6800 UD16950S CST40447AS 5256155 246-31109 S-80571 STN2868 255539 700.527.112 20432744BN 190-90112 6040447.0 10955N STR70481Specifications
Kilowatt | 2.70 kW |
Length (L.1) | 280 mm |
Mount Hole Center - Center (O.1) | 119 mm |
Mount Hole Diameter (C.1) | 13.50 mm |
Mount Hole Diameter (C.2) | 13.50 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
OEM Product | No |
Pinion at Rest (B) | 18 mm |
Product Line | Standard Line |
Product Type | Brand new |
Rotation | CW |
Spigot Diameter (A) | 95 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CUMMINS | Engine 3.3 | [QSB] |
Reference Information
10955N | WAI / TRANSPO |
190-90112 | ROBERT'S |
20432744BN | REAL |
246-31109 | DIXIE |
255539 | KUHNER |
428000-6800 | DENSO |
5256155 | CUMMINS |
6040447.0 | SANDO |
700.527.112 | PSH |
CST40447AS | CASCO |
S-80571 | DIXIE |
STN2868 | KRAUF |
STR70481 | WOODAUTO |
UD16950S | AS-PL |
