Associated Numbers
28100-76090 UD16982SSpecifications
Kilowatt | 1.6 kW |
Length (L.1) | 188 mm |
Mount Hole Center - Center (O.1) | 93.5 mm |
Mount Hole Center - Center (O.2) | 88 mm |
Mount Hole Center - Center (O.3) | 118 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
Mount Hole Diameter (C.3) | M10x1.25 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 21 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Previa 2.4 | 01.1997-12.1997 | |
TOYOTA | Previa 2.4 | 01.1994-12.1994 | |
TOYOTA | Previa 2.4 | 01.1995-12.1995 | |
TOYOTA | Previa 2.4 | 01.1996-12.1996 | |
TOYOTA | Previa 2.4 | 01.1997-12.1997 |
Reference Information
17524N 0986UR1217 28100-76090 0000986UR1217 UD16982S 91-29-5277 17524R 91-29-5277N F042000169 STN0894 000F042000169Video/Publications
0986UR1217 17524N 17524R 28100-76090 91-29-5277 91-29-5277N F042000169 STN0894 UD16982SAdd Your Number
