Associated Numbers
128000-1100 UD16981SSpecifications
Kilowatt | 1.4 kW |
Length (L.1) | 188 mm |
Mount Hole Center - Center (O.1) | 120 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | 13 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 20 mm |
Rotation | CW |
Spigot Diameter (A) | 95 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ISUZU | Campo 2.2 | [3AB1] | 01.1983-12.1991 |
ISUZU | Campo 2.2 | [3AB1] | 01.1986-12.1990 |
TCM | Forklift |
Reference Information
128000-1110 128000-1111 6281-100-002-3 UD16981S 228000-1120 228000-1121 228000-1122 8970489671 8970489670 8970489673 8970489672 25-2038 130.552.092.260 2280001983 91-29-5152 2280001981 8267 89704896711 128000-1102 128000-1101 128000-1100 228000-1130 228000-1131 228000-1132 228000-1133 114260 2280002001 17381R 2280002000 LRS01299 17381N 228080-2003 264-14162 2280002003 2280002002 190-20208 8941702052 228000-1983 228000-3920 228000-1984 8941702050 S12DE0404A2 S-8464 228000-1985 8941702051 228000-1986 228000-3921 6281-100-007-4 8.97049E+11 DSN2129 228000-1980 228000-1981 228000-1982 DRS0359 8970489651 8970489650 8970489652 LRS1299 MAV5000 CGB-23051 89704896611 228000-2284 228000-2283 228000-2000 228000-2286 228000-2285 228000-2002 228000-2001 130.552.092 228000-2003 2280001131 8970489660 2280001132 8970489662 2280001130 8970489661 228000-2280 228000-2282 228000-2281 88214845 130.552.092.050 CGB-23245 8970489663 2280001133Video/Publications
114260 128000-1100 130.552.092 17381N 17381R 2280001130 2280001131 2280001132 2280001133 2280001981 2280001983 2280002000 2280002001 2280002002 2280002003 25-2038 264-14162 8267 8941702050 8941702051 8941702052 8970489660 8970489661 8970489662 8970489672 8970489673 91-29-5152 CGB-23245 DRS0359 LRS01299 LRS1299 MAV5000 S-8464 UD16981SAdd Your Number
