Associated Numbers
063280036010 063721377010 0986023380 101377 101377V 113911 116157 12007 1231963 1233235 1351989 1376305 1385784 1465115 1469721 1756795 20-100-01036 20-100-01052 20450211 220375 25-3345 25-3434 30664494 30667058 30667494 30667874 30795407 3124 32505N 36000221 3M5T-11000-DB 3M5T-11000-DC 42001036 438485 458637 4M5T-11000-FA 4M5T-11000-FB 4M5T-11000-FC 4M5T-11000-FD 590.547.113 6.0142.9 6014112 63280036 6G9N-11000-FA 8603409 8697576 88212622 8EA011611-001 8EA012140-391 8EA738258-281 944280802380 AEU1377 AEY2171 CS1377 CST14112 CST14112AS CST14112ES CST14112GS CST14112OS CST14112RS DRS3969 DRS3969N DS5079 DS5079N EAA-121096 GS001036-A LRS02171 LRS02263 MQS1377 MRS80238 MSN8036 NEU1377 RAS34070 STF1377 STM513 STR61815Specifications
| Kilowatt | 2.2 kW |
| Length (L.1) | 243 mm |
| Mount Hole Center - Center (O.1) | 103 mm |
| Mount Hole Center - Center (O.2) | 66 mm |
| Mount Hole Center - Center (O.3) | 66 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| Mount Hole Diameter (C.3) | M10x1.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | -5.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 63 mm |
| Unit Type | FORD |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | C-Max 2.0 TDCi | [G6DA] | 01.2007-12.2010 |
| FORD | C-Max 2.0 TDCi | [G6DB] | 01.2007-12.2010 |
| FORD | C-Max 2.0 TDCi | [G6DD] | 01.2007-12.2010 |
| FORD | C-Max 2.0 TDCi | [G6DG] | 01.2007-12.2010 |
| FORD | Focus 2.0 TDCi | [G6DA] | 01.2004-12.2012 |
| FORD | Focus 2.0 TDCi | [G6DA] | 01.2006-12.2010 |
| FORD | Focus 2.0 TDCi | [G6DB] | 01.2004-12.2012 |
| FORD | Focus 2.0 TDCi | [G6DB] | 01.2006-12.2010 |
| FORD | Focus 2.0 TDCi | [G6DD] | 01.2004-12.2012 |
| FORD | Focus 2.0 TDCi | [G6DD] | 01.2006-12.2010 |
| FORD | Focus 2.0 TDCi | [G6DG] | 01.2004-12.2012 |
| FORD | Focus 2.0 TDCi | [G6DG] | 01.2006-12.2010 |
| FORD | Focus 2.0 TDCi | [IXDA] | 01.2008-12.2011 |
| FORD | Focus C-Max 2.0 TDCi | [G6DA] | 01.2003-12.2007 |
| FORD | Focus C-Max 2.0 TDCi | [G6DB] | 01.2003-12.2007 |
| FORD | Focus C-Max 2.0 TDCi | [G6DD] | 01.2003-12.2007 |
| FORD | Focus C-Max 2.0 TDCi | [G6DG] | 01.2003-12.2007 |
| FORD | Galaxy 2.0 TDCi | [AZWA] | 01.2006-12.2015 |
| FORD | Galaxy 2.0 TDCi | [QXWA] | 01.2006-12.2015 |
| FORD | Galaxy 2.0 TDCi | [QXWB] | 01.2006-12.2015 |
| FORD | Galaxy 2.0 TDCi | [QXWC] | 01.2006-12.2015 |
| FORD | Galaxy 2.0 TDCi | [UFWA] | 01.2006-12.2015 |
| FORD | Kuga 2.0 TDCi | [G6DG] | 01.2008-12.2012 |
| FORD | Kuga 2.0 TDCi | [UKDA] | 01.2008-12.2012 |
| FORD | Kuga 2.0 TDCi 4x4 | [G6DG] | 01.2008-12.2012 |
| FORD | Kuga 2.0 TDCi 4x4 | [UKDA] | 01.2008-12.2012 |
| FORD | Mondeo 2.0 TDCi | [AZBA] | 01.2007-12.2012 |
| FORD | Mondeo 2.0 TDCi | [AZBA] | 01.2007-12.2015 |
| FORD | Mondeo 2.0 TDCi | [KLBA] | 01.2007-12.2015 |
| FORD | Mondeo 2.0 TDCi | [LPBA] | 01.2007-12.2015 |
| FORD | Mondeo 2.0 TDCi | [QXBA] | 01.2007-12.2015 |
| FORD | Mondeo 2.0 TDCi | [QXBB] | 01.2007-12.2015 |
| FORD | Mondeo 2.0 TDCi | [TYBA] | 01.2007-12.2015 |
| FORD | Mondeo 2.0 TDCi | [UFBA] | 01.2007-12.2015 |
| FORD | Mondeo 2.0 TDCi | [UFBB] | 01.2007-12.2015 |
| FORD | S-Max 2.0 TDCi | [AZWA] | 01.2006-12.2014 |
| FORD | S-Max 2.0 TDCi | [QXWA] | 01.2006-12.2014 |
| FORD | S-Max 2.0 TDCi | [QXWB] | 01.2006-12.2014 |
| FORD | S-Max 2.0 TDCi | [QXWC] | 01.2006-12.2014 |
| FORD | S-Max 2.0 TDCi | [UFWA] | 01.2006-12.2014 |
Reference Information
DRS0161N MAV161120 8697576 CS1377 590.547.113.230 DRS3969 MQS1377 30667058-A GS001036VI-R 1756795 SS001036VI-R 3M5T-11000-DC F042S0H071 458637 8603409 AI-80037R 000986023380 6014112.1 590.547.113.239 30667494 331888 DRS0156N 590.547.113.235 1469721 1385784 CST14112GS 25-3434 LRS02263 3124 STR8015 20-100-01036 20450211BN SG0389 DRS0161 3M5T-11000-DB 3M5T-11000-DA 9.44281E+11 220375 5014058 PRSS223 VP3M5U-11131-AA AEU1377 MSRC1377 113911 DS1271N 438485 1231963 438400 1465115 RM6G9N-11000-FA 1376305 RM6G9N11000FA 8EA738258-281 8EA012140-391 RE6G9N-11000-FA 311515 30795407 101377 1233235 DRS3969N 63280036 AI-80037 30795404 DS5079 EAA-121096 MEE015025 MSN8036 RE6G9N11000FA 101377M 590.547.113.029 590.547.113.028 101377V 63280036010 32505N 6.0142.9 LRS2171 42001036 RAS34070 STX200024R 6612N 20450211OE 3M5TDC 30667058 GS001036-A NEU1377 SG1153 8EA011611-001 6G9N-11000-FA 2S0034 12007 AEY2171 986023380 30664494 201019 DS5079N 3M5U-11131-AA 6GN9-11000-FA 25-3345 116157 9.43214E+11 6014112 MRS80238 STR61815 ANM16189X 30667874 4M5T-11000-FD S12VS0036A2 1351989 LRS02171 STF1377 SS001036-A STM513 63721377010 36000221 8697576-A 590.547.113.020 STRS223 88212622 4M5T-11000-FA 4M5T-11000-FB LRS2263 4M5T-11000-FC S12VS0036 20-100-01052 CST14112ASVideo/Publications
101377 STF1377 6.0142.9 42001036 8EA738258-281 8EA012140-391 8EA011611-001 CS1377 GS001036-A SG0389 6G9N-11000-FA 3M5U-11131-AA 1756795 1469721 1465115 1385784 1376305 1351989 1233235 1231963 220375 25-3434 12007 RAS34070 DS5079N DS1271N DRS3969N DRS0161N CST14112GS CST14112AS 116157 113911 0986023380 NEU1377 AEY2171 AEU1377 AI-80037R 590.547.113.239 590.547.113.230 590.547.113.020 88212622 MEE015025 MSRC1377 MSN8036 MRS80238 MQS1377 944280802380 943213771010 63280036 063721377010 063280036010 LRS2263 LRS02263 101377V 101377M 20450211BN 20450211OE 2S0034 STM513 6014112.0 6014112.1 MAV161120 201019 438400 438485 458637 20-100-01036 20-100-01052 30667058 30667058-A 30667494 36000221 8603409 8697576-A 32505NAdd Your Number
