Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
HYUNDAI / KIA
Price:
NZ$ 397.20 including GST
NZ$ 345.39 excluding GST
or four payments of $99.30
with
Learn More
UOM:
each
Product Code:
S9081
1
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
OK620-18-400Associated Numbers
25-4197 LRS02525 OK620-18-400 OK620-18-400A
mxs211 SNJ073 SNJ073GQ
25-4197 ELSTOCK
OK620-18-400 HYUNDAI / KIA
OK620-18-400A HYUNDAI / KIA
LRS02525 LUCAS
Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 240 mm |
| Mount Hole Center - Center (O.1) | 85.50 mm |
| Mount Hole Center - Center (O.2) | 82 mm |
| Mount Hole Center - Center (O.3) | 134 mm |
| Mount Hole Diameter (C.1) | 13.50 mm |
| Mount Hole Diameter (C.2) | M12x1.5 mm |
| Mount Hole Diameter (C.3) | 13.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 13 qty |
| No./Teeth (Replaces) | 13 qty |
| OEM Product | No |
| On Sale Item | Yes |
| Pinion at Rest (B) | 42 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 90 mm |
| Unit Type | HYUNDAI / KIA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| KIA | Ceres 2.4 D | [SC] |
Reference Information
| 25-4197 | ELSTOCK |
| LRS02525 | LUCAS |
| LRS2525 | LUCAS |
| OK620-18-400 | HYUNDAI / KIA |
| OK620-18-400A | HYUNDAI / KIA |
| STR6382 | ELECTROLOG |
Video/Publications
