Associated Numbers
03101-3011 UD00652SSpecifications
Kilowatt | 2 kW |
Length (L.1) | 240 mm |
Mount Hole Center - Center (O.1) | 85.5 mm |
Mount Hole Center - Center (O.2) | 81.5 mm |
Mount Hole Center - Center (O.3) | 134 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | M12x1.5 mm |
Mount Hole Diameter (C.3) | 13.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 13 qty |
No./Teeth (Replaces) | 13 qty |
Pinion at Rest (B) | 42 mm |
Rotation | CW |
Spigot Diameter (A) | 90 mm |
Unit Type | HYUNDAI / KIA |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
KIA | K2400 |
Reference Information
03101-3011 UD00652SVideo/Publications
03101-3011 UD00652SAdd Your Number
