- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Add Your Number
Associated Numbers
0-24000-3150 0-24000-3151 114267 1811003380 1811003381 185-24011 19868 19868N 20446226OE 246-25227 6050622 91-28-4069 CST50622GS S9140 UD02164SSpecifications
| Kilowatt | 4.5 kW |
| Length (L.1) | 294 mm |
| Mount Hole Center - Center (O.1) | 111 mm |
| Mount Hole Center - Center (O.2) | 136 mm |
| Mount Hole Center - Center (O.3) | 111 mm |
| Mount Hole Diameter (C.1) | 13.5 mm |
| Mount Hole Diameter (C.2) | 13.5 mm |
| Mount Hole Diameter (C.3) | 13.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| No./Teeth (Replaces) | 11 qty |
| Pinion at Rest (B) | 41 mm |
| Rotation | CW |
| Spigot Diameter (A) | 105 mm |
| Unit Type | NIKKO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| JOHN DEERE | 225C | [6BG1T] | 01.1999- |
Reference Information
8983763930 185-24011 1811003380 254572 S9140 131.515.113.710 220633 6050622.1 1811003310 91-28-4069 254572K 5150161 19868 20446226BN STR8819 0-61000-0250 19868N CST50622AS 0-24000-3151 0-24000-3150 CST50622GS 131.515.113.170 S24NK0029A2 246-25227 1811003381 114267 6050622 STK4267 UD02164S 20446226OEVideo/Publications
0-24000-3150 0-24000-3151 114267 1811003380 1811003381 185-24011 19868 19868N 20446226OE 246-25227 6050622 91-28-4069 CST50622GS S9140 UD02164SAdd Your Number
