Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
ISKRA / LETRIKA
Price:
NZ$ 678.98 including GST
NZ$ 590.42 excluding GST
or four payments of $169.75
with
Learn More
each
S9143
No stock in NZ currently
No stock in NZ currently
Associated Numbers
11.131.053 11.131.522 11.131.638 5423.3708000-10 8912.3708 91123708 AZF4163 AZJ3367 AZJ3436 AZJ4163 CT142B CT142B2 IS1172 IS1228 M9T9112 MS616 S9143 ST142 02.490 STI4163 STR4163 STR8163 STR9163 TM255 UD01378SSpecifications
| Kilowatt | 6 kW |
| Length (L.1) | 301 mm |
| Mount Hole Center - Center (O.1) | 142 mm |
| Mount Hole Center - Center (O.2) | 35 mm |
| Mount Hole Center - Center (O.3) | 103 mm |
| Mount Hole Center - Center (O.4) | 92 mm |
| Mount Hole Diameter (C.1) | 17.50 mm |
| Mount Hole Diameter (C.2) | 17.50 mm |
| Mount Hole Diameter (C.3) | 17.50 mm |
| Mount Hole Diameter (C.4) | 17.50 mm |
| No./Mount holes | 4 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| No./Teeth (Replaces) | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 45 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 100 mm |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| KAMAZ | 4208 10.9 | [7408.10] | |
| KAMAZ | 4211 10.9 | [7403.10] | |
| KAMAZ | 52997 10.9 | [740.13-260] | |
| KAMAZ | 52999 10.9 | [740.11-240] | |
| KAMAZ | 52999 10.9 | [740.22-240] | |
| KAMAZ | 53125 10.9 | [740.31-240] | |
| KAMAZ | 5320 10.9 | [740.10] | |
| KAMAZ | 5511 10.9 | [740.11-240] | |
| KAMAZ | 6540 10.9 | [740.13-260] | |
| KAMAZ | Engine 10.9 | [740.10] | |
| KAMAZ | Engine 10.9 | [740.11-240] | |
| KAMAZ | Engine 10.9 | [740.13-260] | |
| KAMAZ | Engine 10.9 | [740.22-240] | |
| KAMAZ | Engine 10.9 | [7403.10] | |
| KAMAZ | Engine 10.9 | [7408.10] | |
| LIAZ | 5256 10.8 4x2 | [7403.10] | |
| LIAZ | 5256 10.9 4x2 | [740.10] | |
| LIAZ | 5256 10.9 4x2 | [740.13-260] | |
| LIAZ | 5256.40 10.9 4x2 | [740.11-240] | |
| LIAZ | 52565 10.9 4x2 | [7408.10] |
Reference Information
| 361.501.104.500 | PSH |
| 91123708 | KATEK |
| M9T9112 | KATEK |
| S9143 | AS-PL |
| STI4163 | KRAUF |
| STR4163 | KRAUF |
| STR8163 | KRAUF |
| STR9163 | KRAUF |
| TM255 | ISKRA / LETRIKA |
| UD01378S | AS-PL |
Video/Publications
