Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
NIKKO
Price:
NZ$ 362.87 including GST
NZ$ 315.54 excluding GST
or four payments of $90.72
with
Learn More
each
S9165
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Associated Numbers
028000-9761 246-25217 28100-1660 28100-1900A S9165 UD11108S 16-034 dxs4027Specifications
| Kilowatt | 4.50 kW |
| Length (L.1) | 296 mm |
| Mount Hole Center - Center (O.1) | 153 mm |
| Mount Hole Diameter (C.1) | 15.50 mm |
| Mount Hole Diameter (C.2) | M14x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 31 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 105 mm |
| Unit Type | NIKKO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HINO | Engine | [IW] | 01.1986-12.1994 |
| HINO | Engine | [W04D] | 01.1983-12.1992 |
Reference Information
| 028000-9761 | NIKKO |
| 246-25217 | DIXIE |
| 28100-1660 | NIKKO |
| 28100-1900A | NIKKO |
| S9165 | AS-PL |
| UD11108S | AS-PL |
