- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Add Your Number
Associated Numbers
0-23000-7670 0-23000-7671 0-23000-7672 20446236OE 244-11201C 600-813-9310 600-813-9311 600-813-9312 6050632 91-28-4061 941.513.123 CST50632GS DRS0527 S-80196 UD11101SSpecifications
Kilowatt | 11 kW |
Length (L.1) | 428 mm |
Mount Hole Center - Center (O.1) | 114 mm |
Mount Hole Center - Center (O.2) | 140 mm |
Mount Hole Center - Center (O.3) | 168 mm |
Mount Hole Diameter (C.1) | 15 mm |
Mount Hole Diameter (C.2) | 15 mm |
Mount Hole Diameter (C.3) | 15 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
No./Teeth (Replaces) | 12 qty |
Pinion at Rest (B) | 29 mm |
Rotation | CW |
Spigot Diameter (A) | 105 mm |
Unit Type | NIKKO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
KOMATSU | D155AX-3 | [SA6S140] | 01.1999- |
KOMATSU | D155AX-5 | [SA6S140] | 01.1999- |
Reference Information
UD11101S S-80196 0-23000-7671 91-28-4061 0-23000-7672 CST50632GS 244-11201C 6008138310 600-813-9311 DRS0527 6008139430 600-813-9312 6008139431 600-813-9310 6050632 CGB-97671 20446236OEVideo/Publications
0-23000-7671 0-23000-7672 20446236OE 244-11201C 600-813-9310 600-813-9311 600-813-9312 6050632 91-28-4061 CGB-97671 CST50632GS DRS0527 S-80196 UD11101SAdd Your Number
