Associated Numbers
0350-602-0230 S9192 UD11116SSpecifications
Kilowatt | 7 kW |
Length (L.1) | 435 mm |
Mount Hole Center - Center (O.1) | 146 mm |
Mount Hole Center - Center (O.2) | 153 mm |
Mount Hole Center - Center (O.3) | 105 mm |
Mount Hole Diameter (C.1) | 15.5 mm |
Mount Hole Diameter (C.2) | 15.5 mm |
Mount Hole Diameter (C.3) | 15.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 40 mm |
Rotation | CW |
Spigot Diameter (A) | 122 mm |
Unit Type | SAWAFUJI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NISSAN | Engine | [RF8] |
Reference Information
S9192 0350-602-0230 UD11116SVideo/Publications
0350-602-0230 S9192 UD11116SAdd Your Number
