Associated Numbers
0-23000-6070 0-23000-6071 0-23000-6072 114442 1811002161 185-296 S9195 STR5222Specifications
Kilowatt | 6 kW |
Length (L.1) | 407 mm |
Mount Hole Center - Center (O.1) | 169 mm |
Mount Hole Center - Center (O.2) | 115 mm |
Mount Hole Center - Center (O.3) | 142 mm |
Mount Hole Diameter (C.1) | 15.5 mm |
Mount Hole Diameter (C.2) | 15.5 mm |
Mount Hole Diameter (C.3) | 15.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 22.5 mm |
Rotation | CW |
Spigot Diameter (A) | 105 mm |
Unit Type | NIKKO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ISUZU | Various Models |
Reference Information
185-296 0-23000-6070 0-23000-6071 114442 STR5222 1811002161 S9195 0-23000-6072Video/Publications
0-23000-6070 0-23000-6071 0-23000-6072 114442 1811002161 185-296 S9195 STR5222Add Your Number
