- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Add Your Number
Associated Numbers
11.131.527 114677 25-4433 30253N 50496200 50496201 72735768 730.505.092 AZE2605 AZE2662 DRS0266 LETIS1149 LRS02760 MS140 S-6582 STR60696 UD11904(LETRIKA)SSpecifications
Kilowatt | 2 kW |
Length (L.1) | 233 mm |
Mount Hole Center - Center (O.1) | 102 mm |
Mount Hole Diameter (C.1) | 12.5 mm |
Mount Hole Diameter (C.2) | 12.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 41 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | ISKRA / LETRIKA |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HATZ | Engine | [1D41] | 01.2007- |
Reference Information
72735768 AZE2662 6021118.1 S-6582 5065805 LETIS1149 25-4433 30253N AZE2605 730.505.092 50496201 50496200 98417134 STR60696 MS140 MS CST21118GS 1721000 114677 140 20419811BN CST21118AS 6021118 11.131.527 LRS02760 20419811OE LRS2760 UD11904(LETRIKA)S STR79203Video/Publications
11.131.527 114677 25-4433 30253N 50496200 50496201 72735768 730.505.092 AZE2605 AZE2662 LETIS1149 LRS02760 LRS2760 MS 140 MS140 S-6582 STR60696 UD11904(LETRIKA)SAdd Your Number
