- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Add Your Number
Associated Numbers
0001360023 0001360036 0001368030 0986011370 10726 1097 1097P 11.130.766 112132 182-30251 19024274 19084012 19782N 20401416BN 22.0726 243007 260-67207 33898 45-0354 4785541 4880691 6010614 811.001.093 857472GB 8668 8811370 AZJ3277 CS726 CST10614 CST10614AS CST10614ES CST10614GS CST10614OS CST10614RS DRS1280 DRS1370 EAA-111142 EAA-151265 IS0766 LETIS0766 LRS00796 MS319 STR50164 UD11888(LETRIKA)SSpecifications
Kilowatt | 4 kW |
Length (L.1) | 337 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | ISKRA / LETRIKA |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VOLVO BM | 4400 5.5 | [D60A] | 01.1976-06.1979 |
VOLVO BM | D45 | 06.1983-06.1994 | |
VOLVO BM | LM621 4.0 | [D42A] | 12.1973-06.1978 |
VOLVO BM | LM641 4.0 | [D42A] | 12.1973-06.1978 |
VOLVO BM | LM841 5.5 | [D50B] | 01.1976-06.1979 |
VOLVO BM | LM841 5.5 | [D60A] | 01.1976-06.1979 |
VOLVO BM | LM845 5.0 | [D50B] | 01.1971-12.1973 |
VOLVO BM | LM846 5.5 | [D50B] | 01.1976-06.1979 |
VOLVO BM | LM846 5.5 | [D60A] | 01.1976-06.1979 |
Reference Information
1368030 AZJ3277 EAA-151265 0001368030 IS0766 STR7838 CST10614OS 22.0726 33898 3097086M91 112132 8811370 19024274 319 CS726 1360036 0001360023 243007 6010614 MS 20401416BN LETIS0766 4880691 857472GB S24BH0151A2 000986011370 220230 CST10614GS STR50164 11.130.766 1097P 1360023 DRS1370 LRS796 19084012 CST10614 EAA-111142 260-67207 LRS00796 UD11888(LETRIKA)S MS319 8668 9004880691 CST10614RS DRS1280 1097 45-0354 182-30251 CST10614ES 986011370 10726 811.001.093 CST10614AS 0001360036 4785541 19782NVideo/Publications
0001360023 0001360036 0001368030 0986011370 10726 1097 1097P 11.130.766 112132 182-30251 19024274 19084012 19782N 20401416BN 22.0726 243007 260-67207 33898 45-0354 4785541 4880691 6010614 811.001.093 857472GB 8668 8811370 AZJ3277 CS726 CST10614 CST10614AS CST10614ES CST10614GS CST10614OS CST10614RS DRS1280 DRS1370 EAA-111142 EAA-151265 IS0766 LETIS0766 LRS00796 LRS796 MS 319 MS319 STR50164 UD11888(LETRIKA)S 220230Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Starter Motors.
