Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
ISKRA / LETRIKA
Price:
NZ$ 574.17 including GST
NZ$ 499.28 excluding GST
or four payments of $143.54
with
Learn More
each
S9274
1
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
11.131.237Associated Numbers
11.131.237 182-30324 25-5061 6632415 72736044 8263 AL70852 AL81154 AZF4570 EAA-112205 IS1157 LRS03898 MAHMS416 MS416 RE503226 RE504807 SG2000 UD13181SSpecifications
| Kilowatt | 4.20 kW |
| Length (L.1) | 322 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11.50 mm |
| Mount Hole Diameter (C.2) | 11.50 mm |
| Mount Hole Diameter (C.3) | 11.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 48 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| JOHN DEERE | 6140 J 6.8 | [6068?] | |
| JOHN DEERE | 6155 J 6.8 | [6068?] | |
| JOHN DEERE | 6505 6.8 | [6068] | |
| JOHN DEERE | 6506 4.5 | [6068] | |
| JOHN DEERE | 6510 | [4045T] | 01.1998-01.2001 |
| JOHN DEERE | 6510L | [4045T] | 01.1998-01.2001 |
| JOHN DEERE | 6510S | [4045T] | 01.1998-01.2001 |
| JOHN DEERE | 6515 6.8 | [6068DL070] | |
| JOHN DEERE | 6515 6.8 | [6068DL071] | |
| JOHN DEERE | 6520 L 4.6 | [4045HL273] | 01.2002-01.2005 |
| JOHN DEERE | 6520 L 4.6 | [4045T] | 01.2002-01.2005 |
| JOHN DEERE | 6520 L 6.8 | [6068DL..] | 01.2002-12.2007 |
| JOHN DEERE | 6520 L 6.8 | [6068HL..] | 01.2002-12.2007 |
| JOHN DEERE | 6520 L 6.8 | [6068TL..] | 01.2002-12.2007 |
| JOHN DEERE | 6520 SE 4.6 | [4045HL273] | 01.2002-01.2005 |
| JOHN DEERE | 6520 SE 4.6 | [4045T] | 01.2002-01.2005 |
| JOHN DEERE | 6520 SE 6.8 | [6068DL..] | 01.2002-12.2007 |
| JOHN DEERE | 6520 SE 6.8 | [6068HL..] | 01.2002-12.2007 |
| JOHN DEERE | 6520 SE 6.8 | [6068TL..] | 01.2002-12.2007 |
| JOHN DEERE | 6605 6.8 | [6068T] | 01.2002-12.2007 |
| JOHN DEERE | 6610 SE 6.8 | [6068T] | 01.1997-12.2002 |
| JOHN DEERE | 6615 6.8 | [6068HL271] | 01.2002-01.2005 |
| JOHN DEERE | 6620 6.8 | [6068HL272] | |
| JOHN DEERE | 6620 6.8 | [6068HLA070] | |
| JOHN DEERE | 6620 6.8 | [6068TL072] | 01.2002-01.2005 |
| JOHN DEERE | 6620 SE 6.8 | [6068HL272] | |
| JOHN DEERE | 6620 SE 6.8 | [6068TL072] | |
| JOHN DEERE | 6715 6.8 | [6068HL273] | |
| JOHN DEERE | 6715 6.8 | [6068TL072] | |
| JOHN DEERE | 6810 6.8 | [6068TLA] | 01.1997-12.2001 |
| JOHN DEERE | 6820 6.8 | [6068HL472] | 01.1997-01.2005 |
| JOHN DEERE | 6820 6.8 | [6068HLA71] | 01.1997-01.2005 |
| JOHN DEERE | 6910 S 6.8 | [6.0685S] | 01.1997-12.2001 |
| JOHN DEERE | 6910 S 6.8 | [6.068TLA] | 01.1997-12.2001 |
| JOHN DEERE | 6920 6.8 | [6068HL472] | 01.1997-01.2005 |
| JOHN DEERE | 6920 6.8 | [6068HLA71] | 01.1997-01.2005 |
| JOHN DEERE | 6920 S 6.8 | [6068HL474] | |
| JOHN DEERE | 6920 S 6.8 | [6068HLA73] | |
| JOHN DEERE | 6920 SE 6.8 | [6068TL074] | |
| JOHN DEERE | 7220 6.8 | [6068HRW..] | |
| JOHN DEERE | 7220 6.8 | [6068TP..] | |
| JOHN DEERE | 7220 6.8 | [6068TRW..] | |
| JOHN DEERE | 7320 6.8 | [6068HRW..] | |
| JOHN DEERE | 7320 6.8 | [6068TP..] | |
| JOHN DEERE | 7320 6.8 | [6068TRW..] | |
| JOHN DEERE | 7420 6.8 | [6068] | |
| JOHN DEERE | 7420 6.8 | [6068HRW..] | |
| JOHN DEERE | 7420 6.8 | [6068TP..] | |
| JOHN DEERE | 7420 6.8 | [6068TRW..] | |
| JOHN DEERE | 7425 6.8 | [6068] | |
| JOHN DEERE | 7520 6.8 | [6068] | |
| JOHN DEERE | 7520 6.8 | [6068HRW..] | |
| JOHN DEERE | 7520 6.8 | [6068TP..] | |
| JOHN DEERE | 7520 6.8 | [6068TRW..] | |
| JOHN DEERE | 7525 6.8 | [6068] |
Reference Information
| 11.131.237 | ISKRA / LETRIKA |
| 182-30324 | ROBERT'S |
| 25-5061 | ELSTOCK |
| 6632415 | BOBCAT |
| 72736044 | MAHLE |
| 8263 | CEVAM |
| AL70852 | JOHN DEERE |
| AL81154 | JOHN DEERE |
| AZF4570 | ISKRA / LETRIKA |
| CGB-20002 | AINDE |
| CGB-23818 | AINDE |
| IS1157 | ISKRA / LETRIKA |
| LRS03898 | LUCAS |
| LRS3898 | LUCAS |
| MAHMS416 | WOODAUTO |
| MAV122280 | SIOM |
| MS416 | MAHLE |
| MS 416 | MAHLE |
| RE503226 | JOHN DEERE |
| RE504807 | JOHN DEERE |
| S9274 | AS-PL |
| SE501855 | JOHN DEERE |
| SG2000 | GHIBAUDI |
| STR7818 | ELECTROLOG |
| STX200383 | STARDAX |
| STX200904 | STARDAX |
| STX201006 | STARDAX |
| STX201072 | STARDAX |
| UD13181S | AS-PL |
