Brand new OEM ISKRA / LETRIKA Starter motor
PREMIUM LINE
Letrika
ISKRA / LETRIKA
Price:
NZ$ 1,338.47 including GST
NZ$ 1,163.89 excluding GST
or four payments of $334.62
with
Learn More
each
S9297(LETRIKA)
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
MS312Associated Numbers
11.130.534 630.002.102 91-23-6549 AZJ3158 IS0534 MAHMS312 MS312 UD809680(LETRIKA)SSpecifications
| Kilowatt | 3 kW |
| Length (L.1) | 338 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | 13.50 mm |
| Mount Hole Diameter (C.2) | 13.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| OEM Product | Yes |
| Pinion at Rest (B) | 34 mm |
| Product Line | Premium Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82.50 mm |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| JOHN DEERE | 1020 2.7 | [3.164DL-04] | 04.1971-07.1975 |
| JOHN DEERE | 1030 2.7 | [3.164DL-04] | 08.1975-08.1979 |
| JOHN DEERE | 1030 OU 2.7 | [3.164DL-04] | 08.1975-08.1979 |
| JOHN DEERE | 1040 2.9 | [3.179DL-06] | 09.1979-10.1986 |
| JOHN DEERE | 1040V 2.9 | [3.179DL-06] | 09.1979-10.1986 |
| JOHN DEERE | 1130 2.7 | [3.164DL-13] | 08.1975-08.1979 |
| JOHN DEERE | 1140 2.9 | [3.179DL-01] | 09.1979-10.1986 |
| JOHN DEERE | 1140F 2.9 | [3.179DL-01] | 09.1979-10.1986 |
| JOHN DEERE | 1140V 2.9 | [3.179DL-01] | 09.1979-10.1986 |
| JOHN DEERE | 1530 2.7 | [3.164DL-13] | 07.1972-07.1975 |
| JOHN DEERE | 3130 5.4 | [6.329DL-11] | 09.1972-08.1979 |
| JOHN DEERE | 3140 5.9 | [6.359DL-03] | 09.1979-05.1987 |
| JOHN DEERE | MD 1065 5.9 | [6.359TZ-03] | 03.1994- |
| JOHN DEERE | MD 1075 5.9 | [6.359TZ-02] | 03.1994- |
| JOHN DEERE | MD 1085 5.9 | [6.466TZ-01] | 03.1994- |
| JOHN DEERE | MD 925 2.7 | [3.164DZ-02] | 07.1975-09.1978 |
| JOHN DEERE | MD 952 3.9 | [4.239TZ-01] | 11.1977-10.1983 |
| JOHN DEERE | MD 955 5.4 | [6.329DZ-02] | 06.1975-01.1981 |
| JOHN DEERE | MD 960 5.4 | [6.329DZ-02] | 08.1972-08.1974 |
| JOHN DEERE | MD 965 5.9 | [6.359TZ-03] | 09.1975-10.1983 |
| JOHN DEERE | MD 968H 5.9 | [6.359TZ-03] | 04.1981-10.1983 |
| JOHN DEERE | MD 970 5.9 | [6.359TZ-01] | 09.1974-07.1975 |
| JOHN DEERE | MD 975 5.9 | [6.359TZ-02] | 09.1975-05.1981 |
Reference Information
| 11.130.534 | ISKRA / LETRIKA |
| 33418 | EAI |
| 630.002.102.011 | PSH |
| 630.002.102.017 | PSH |
| 630.002.102.019 | PSH |
| 630.002.102.312 | PSH |
| 630.002.102.313 | PSH |
| 630.002.102.395 | PSH |
| 72735940 | MAHLE |
| 8687 | CEVAM |
| 91-23-6549 | WILSON |
| AZJ3158 | ISKRA / LETRIKA |
| IS0534 | ISKRA / LETRIKA |
| MAHMS312 | WOODAUTO |
| MS312 | MAHLE |
| S134.227 | PSH |
| S144.087 | PSH |
| STB0395 | KRAUF |
| STR7916 | ELECTROLOG |
| TS-6010 | DIXIE |
| UD809680(LETRIKA)S | AS-PL |
Video/Publications
