Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MANDO
Price:
NZ$ 258.23 including GST
NZ$ 224.55 excluding GST
or four payments of $64.56
with
Learn More
each
S9345S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
M53436Associated Numbers
111307 11850 1250299 17709N 17709R 20493201 20923 220383 25-2142 36100-23100 36100-23105 36100-23150 36100-23161 455739 455969 6032102 88212214 8EA011610-911 8EA012140-151 8EA737124-001 91-31-9009 944280800780 AES2203 CST32102 CST32102AS CST32102ES CST32102GS CST32102OS CST32102RS D6RA78 DRS3577 DS4687 J5210500 J5210518 JS923 LRT00203 M53436 M53486 MP112056 MRS80078 RAS34688 S-8589 S1135M SG0225 STA0923 STA9933 STM0923 STM1048 STR75001 STV0923 TM000A08401 UD20464SSpecifications
| Kilowatt | 1.20 kW |
| Length (L.1) | 208 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 8 qty |
| OEM Product | No |
| Pinion at Rest (B) | 18 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 77 mm |
| Unit Type | MANDO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | Coupe 1.6 16V | [G4GR] | 03.1998-04.2002 |
| HYUNDAI | Coupe 1.6 i 16V | [4G61] | 12.1996-04.2002 |
| HYUNDAI | Coupe 2.0 | [G4GC-G] | 03.2002- |
| HYUNDAI | Coupe 2.0 16V | [G4GF] | 08.1996-04.2002 |
| HYUNDAI | Coupe 2.0 GLS | [G4GC-G] | 02.2003- |
| HYUNDAI | Elantra 1.6 GL | 01.1992-01.1995 | |
| HYUNDAI | Elantra 1.8 | [G4BB] | 06.2000- |
| HYUNDAI | Elantra 1.8 | [G4CN] | 01.1998-01.1998 |
| HYUNDAI | Elantra 1.8 | [G4GB] | 11.2002- |
| HYUNDAI | Elantra 1.8 | 01.1996-01.1997 | |
| HYUNDAI | Elantra 1.8 GLS | 01.1996-01.1997 | |
| HYUNDAI | Elantra 2.0 | [G4CP] | 01.1999-01.1999 |
| HYUNDAI | Elantra 2.0 | [G4CP] | 01.2000-01.2001 |
| HYUNDAI | Elantra 2.0 | [G4GC] | 06.2000-07.2006 |
| HYUNDAI | Elantra 2.0 | [G4GC] | 10.2003-07.2006 |
| HYUNDAI | Elantra 2.0 | [G4GC-G] | 06.2000- |
| HYUNDAI | Elantra 2.0 | [G4GC-G] | 06.2000-07.2006 |
| HYUNDAI | Elantra 2.0 GLS | [G4CP] | 01.2002-01.2002 |
| HYUNDAI | Elantra 2.0 GLS | [G4CP] | 01.2003-01.2003 |
| HYUNDAI | Elantra 2.0 GT | [G4CP] | 01.2002- |
| HYUNDAI | Elantra 2.0 GT | [G4CP] | 01.2003-01.2003 |
| HYUNDAI | Lantra 1.6 | [G4GR] | 02.1996- |
| HYUNDAI | Lantra 1.6 | [G4GR] | 11.1995-09.2000 |
| HYUNDAI | Lantra 1.6 16V | [4G61] | 02.1996- |
| HYUNDAI | Lantra 1.6 16V | [4G61] | 11.1995-09.2000 |
| HYUNDAI | Lantra 1.8 16V | [G4GM] | 02.1996- |
| HYUNDAI | Lantra 1.8 16V | [G4GM] | 11.1995-09.2000 |
| HYUNDAI | Lantra 2.0 16V | [G4GF] | 08.1996-09.2000 |
| HYUNDAI | Lantra 2.0 16V | [G4GF] | 12.1996- |
| HYUNDAI | Matrix 1.8 | [G4GB-G] | 06.2001- |
| HYUNDAI | Sonata 2.7 V6 | [G6BA] | 11.2002-11.2004 |
| HYUNDAI | Tiburon 1.8 | 01.1997-01.1997 | |
| HYUNDAI | Tiburon 2.0 | [G4CP] | 01.1998-01.2001 |
| HYUNDAI | Tiburon 2.0 FX | [G4CP] | 01.1998-01.1998 |
| HYUNDAI | Tiburon 2.0 FX | 01.1997-01.1997 | |
| HYUNDAI | Tucson 2.0 | [G4GC] | 08.2004-03.2010 |
| HYUNDAI | Tucson 2.0 4WD | [G4GC] | 08.2004-03.2010 |
| KIA | Cerato 2.0 | [G4GC] | 04.2004- |
Reference Information
| 003-C125 | ASHIKA |
| 111307 | CARGO |
| 11850 | CEVAM |
| 1250299 | VALEO |
| 17709N | WAI / TRANSPO |
| 17709R | WAI / TRANSPO |
| 20493201 | REAL |
| 20923 | KUHNER |
| 220383 | ERA |
| 25-2142 | ELSTOCK |
| 36100-23100 | HYUNDAI / KIA |
| 36100-23105 | HYUNDAI / KIA |
| 3610023120 | HYUNDAI / KIA |
| 36100-23120 | HYUNDAI / KIA |
| 36100-23150 | HYUNDAI / KIA |
| 3610023160 | HYUNDAI / KIA |
| 36100-23160 | HYUNDAI / KIA |
| 36100-23161 | HYUNDAI / KIA |
| 3610023165 | HYUNDAI / KIA |
| 36100-23165 | HYUNDAI / KIA |
| 3C125 | JAPKO |
| 455739 | VALEO |
| 455969 | VALEO |
| 6032102 | SANDO |
| 88212214 | POWERMAX |
| 8EA011610-911 | HELLA |
| 8EA012140-151 | HELLA |
| 8EA737124-001 | HELLA |
| 91-31-9009 | WILSON |
| 944280800780 | MAGNETI MARELLI |
| AES2203 | AUTOELECTRO |
| ASM1041 | APEC |
| CGB-23013 | AINDE |
| CST32102 | CASCO |
| CST32102AS | CASCO |
| CST32102ES | CASCO |
| CST32102GS | CASCO |
| CST32102OS | CASCO |
| CST32102RS | CASCO |
| D6RA78 | VALEO |
| DRS3577 | DELCO |
| DS4687 | DELCO |
| F032111307 | CARGO |
| GSL600060 | HYUNDAI / KIA |
| H3610023100 | HYUNDAI / KIA |
| H3610-023100 | HYUNDAI / KIA |
| H3610023120 | HYUNDAI / KIA |
| H3610-023120 | HYUNDAI / KIA |
| J5210500 | HERTH+BUSS |
| J5210518 | HERTH+BUSS |
| JS923 | HC PARTS |
| K3610023100 | HYUNDAI / KIA |
| K36100-23100 | HYUNDAI / KIA |
| K3610023120 | HYUNDAI / KIA |
| KG3610023120 | HYUNDAI / KIA |
| LRT00203 | LUCAS |
| M53436 | MANDO |
| M53486 | MANDO |
| MAV7230 | SIOM |
| MP112056 | MANDO |
| MRS80078 | MAGNETI MARELLI |
| MTC125 | JAPANPARTS |
| NPANSM1041 | NAPA |
| RAS34688 | DELCO |
| S1135M | PRESTOLITE |
| S12VA0325A2 | SIDAT |
| S-8589 | DIXIE |
| SG0225 | GHIBAUDI |
| STA0923 | KRAUF |
| STA9933 | KRAUF |
| STM0923 | KRAUF |
| STM1048 | ROLLCO |
| STR75001 | WOODAUTO |
| STR8702 | ELECTROLOG |
| STRS516 | 3EFFE |
| STV0923 | KRAUF |
| STX200266 | STARDAX |
| TM000A08401 | VALEO |
| UD20464S | AS-PL |
Video/Publications
