Associated Numbers
063227416010 063227491010 26260F/J 26275F 26275F/K 26275J 26275K 26280F 26280F/J 26280H 26280J 26306E 26306E/H 26306F 26306H 27412 27412A 27412A/D 27412B 27412D 27412H 27416 27416A 27416A/D 27416B 27416D 27423 27423A 27452 27452A 27475 27475A 63227412 63227416 63227475 63227491 063227416010 063227491010 26260F/J 26275F 26275F/K 26275J 26275K 26280F 26280F/J 26280H 26280J 26306E 26306E/H 26306F 26306H 27412 27412A 27412A/D 27412B 27412D 27412H 27416 27416A 27416A/D 27416B 27416D 27423 27423A 27452 27452A 27475 27475A 63227412 63227416 63227475 63227491Specifications
Inside Diameter (I.D.1) | 17 mm |
Length (L.1) | 73.80 mm |
Length (L.2) | 20.50 mm |
No./Splines | 12 qty |
No./Teeth | 13 qty |
OEM Product | No |
Outside Diameter (O.D.1) | 58.60 mm |
Outside Diameter (O.D.2) | 45.60 mm |
Product Line | Standard Line |
Product Type | Brand new |
Rotation | CW |
Type | Drive |
Unit Type | MAGNETI MARELLI |
Reference Information
085541538010 | LUCAS |
1.01.0134.0 | ZEN |
1011460 | POWERMAX |
131729 | CARGO |
25-44-33 | VISNOVA |
2932 | GHIBAUDI |
54247397 | LUCAS |
54-9218 | WAI / TRANSPO |
60600078 | LUCAS |
85541538 | MAGNETI MARELLI |
CQ2010901 | LAUBER |
DRV4077 | ELECTROLOG |
F032131729 | CARGO |
SDL5729 | KRAUF |
SDV3124 | WOODAUTO |
TMB125 | LUCAS |
